ISW Switch 1P 100A 240VAC | DIN Rail Mount | Padlockable Handle | by Clipsal
The ISW Switch 1P 100A 240VAC is a robust switch disconnector designed for reliable circuit isolation in residential and commercial electrical distribution boards. With a padlockable handle for added safety and a compact design for DIN rail mounting, it’s perfect for industrial control panels and switchboards. Compliant with AS/NZS standards, this switch ensures safe and efficient operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: ISW Switch 1P 100A 240VAC | DIN Rail Mount | Padlockable Handle | by Clipsal
Brand: Clipsal
SKU: SCHA9S66191
Alternatively Known As: ISW Switch Disconnector, 1 Pole 100A Switch, Clipsal SCHA9S66191, DIN Rail Isolator Switch, Main Switch 100A 1P
Technical Specifications
- Type: Switch disconnector
- Number of poles: 1P
- Rated current: 100A
- Rated operational voltage: 240VAC
- Frequency: 50/60Hz
- Mounting: DIN rail (2 modules)
- Utilization category: AC-22A
- Padlockable: Yes
- Degree of protection: IP20 (terminals), IP40 (enclosure)
- Standards: IEC 60947-3
- Dimensions (H x L x W): 85mm x 70mm x 36mm
- Weight: 0.15 kg
Key Features
- Single pole (1P) switch disconnector
- Rated current: 100A
- Rated voltage: 240VAC
- 2 module width for DIN rail mounting
- Robust and compact design
- Padlockable handle for added safety
- Clear ON/OFF position indication
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Residential and commercial electrical distribution boards
- Industrial control panels
- Switchboards for lighting and power circuits
- Main and sub-main circuit isolation
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable construction ensures long service life, reducing replacement frequency and waste.
- Compliant with RoHS for reduced hazardous substances.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal ISW Switch 1P 100A 240VAC 2Mod (SCHA9S66191) is available for immediate purchase. Ideal for use in electrical distribution boards and switchboards requiring reliable circuit isolation.
