Jade 1500 1500VA 900W Line Interactive UPS SNMP Chase Power
Chase Power Jade 1500 line interactive UPS 1500VA/900W AVR ECO mode, SNMP-ready. Managed backup for servers and IT.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Jade 1500 UPS, Chase Power Jade 1500 UPS, 1500VA server UPS, SNMP-ready UPS
Technical Specifications
- Capacity: 1500VA/1050W
- Topology: Line interactive pure sinewave
- Input voltage range: 162–290VAC
- Nominal voltage: 208/220/230/240VAC
- Output waveform: Pure sine wave
- Voltage regulation in battery mode: ±1.5% before low-battery alarm
- Transfer time: Typically 2–6ms, 10ms maximum
- Battery: 2 x 12V/9Ah sealed lead-acid batteries
- Typical recharge time: 4 hours to 90% capacity
- Efficiency: Greater than 95% in battery mode
- Communication: HID USB and smart RS-232
- SNMP: Optional SNMP/AS400 card
- Display: LCD status display
- Outlets: 8 power management outlets, including 3 programmable outlets
- Operating environment: 0–40°C, 0–90% RH non-condensing
- Noise level: Less than 45dB
- Connection: 10A power point required
- Dimensions (H x L x W): 236mm x 410mm x 145mm
- Weight: 12.35 kg
Key Features
- Pure sinewave output for servers, networking equipment and sensitive electronics
- Automatic buck and boost AVR for voltage stabilisation
- ECO mode for energy-saving operation
- Programmable power management outlets to prioritise critical equipment runtime
- HID-compliant USB interface for Windows, Linux and Mac systems
- Smart RS-232 communication port
- Optional SNMP/AS400 network management
- Microprocessor control and three-stage smart battery charging
- Built-in EMI/RFI noise filtering
- Emergency Power Off function
- Overload, discharge and overcharge protection
- Supplied with input cable, IEC output cable, Australian adaptor cable, USB cable and user manual
Professional Installation Requirements
- Normally operates as a plug-in UPS and does not require professional installation. Use a suitable 10A Australian power outlet and follow the manufacturer's installation and battery-safety instructions; any fixed electrical work must be completed by a licensed electrician.
Applications
- Server rooms and small data-centre equipment
- Network storage and networking equipment
- Computers and workstations
- Telecommunications and radio equipment
- PABX systems
- Point-of-sale systems
- Surveillance and security systems
- ATM and payment equipment
- NBN and internet equipment
- Medical and other sensitive electronic equipment
Standards & Compliance
- AS 62040.1: Applicable Australian safety standard for portable uninterruptible power supplies
- AS 62040.3: Applicable performance and test requirements for UPS systems
- AS/NZS 3000: Applicable wiring and electrical installation requirements for the connected Australian installation
Environmental Benefits
- ECO mode can reduce energy consumption during suitable operating conditions
- High battery-mode efficiency reduces power losses during outages
- Three-stage smart charging helps support battery service life
- Replaceable sealed lead-acid batteries can extend the usable life of the UPS and reduce electronic waste
- Recyclable metal and electronic components can be recovered through appropriate e-waste and battery recycling channels
Warranty Information
Chase Power states that its UPS warranty is equal to or superior to comparable brands; the specific warranty period for the Jade 1500 should be confirmed with Chase Power or the authorised distributor before purchase.
Available Now
Available through Chase Power and authorised Australian distributors, subject to current distributor stock.
