Jade 2000 2000VA 1400W Pure Sinewave UPS SNMP Chase Power

BRAND: Chase Power
SKU: CP2358
$1,229.90 List price: $1,844.80
+ −
30 Days Return Electricians Unlock Trade Access
Chase Power Jade 2000 line interactive pure sinewave UPS 2000VA/1400W ECO mode SNMP-ready. Backup for sensitive IT.

Alternatively Known As: Jade 2000 UPS, line-interactive pure sinewave UPS, IT battery backup UPS

Technical Specifications
  • Capacity: 2000VA/1400W
  • Topology: Line-interactive pure sinewave
  • Input voltage: 208/220/230/240VAC
  • Acceptable input voltage range: 162–290VAC
  • Output voltage: 208/220/230/240VAC
  • Battery-mode voltage regulation: ±1.5% before battery alarm
  • Transfer time: Typically 2–6ms; 10ms maximum
  • Battery waveform: Pure sinewave
  • Battery type: 12V/7Ah sealed batteries, 4 units
  • Battery-mode efficiency: ≥91%, up to 92% at nominal battery voltage
  • Typical recharge time: 4 hours to 90% capacity
  • Outlets: 8 power management outlets, including 3 programmable outlets
  • Communications: HID-compliant USB and Smart RS-232
  • Network management: Optional SNMP/AS400 card
  • Noise level: Less than 45dB
  • Operating environment: 0–40°C, 0–90% RH non-condensing
  • Connection requirement: 15A power point
  • Dimensions (H x L x W): 236mm x 470mm x 145mm
  • Weight: 18.1 kg
Key Features
  • Pure sinewave output for sensitive IT, communications and electronic equipment
  • Automatic buck and boost AVR for voltage stabilisation
  • ECO mode for energy-saving operation
  • High-resolution LCD display showing operating and fault information
  • Three programmable outlets to prioritise critical equipment runtime
  • Built-in EMI/RFI noise filtering
  • Full-bridge inverter architecture supports half-wave rectified equipment
  • Three-stage smart battery charging control
  • Emergency Power Off function
  • Compatible with Windows, Linux and Mac operating systems
Professional Installation Requirements
  • Use with a compliant 15A outlet. Any new or altered electrical circuit or outlet should be installed by a licensed electrician in accordance with applicable Australian electrical requirements.
Applications
  • Server rooms and network storage
  • Computers and workstations
  • Telecommunications and radio equipment
  • PABX and networking equipment
  • Surveillance and security systems
  • Point-of-sale systems
  • ATM machines
  • Medical and sensitive electronic equipment
  • NBN and internet equipment
  • Hi-fi and other sensitive electronic equipment
Standards & Compliance
  • Applicable UPS safety standard: AS 62040.1:2019
  • Electrical installation work should comply with AS/NZS 3000 where applicable
Environmental Benefits
  • ECO operating mode can reduce energy consumption during suitable operating conditions
  • High battery-mode efficiency helps reduce energy losses during backup operation
  • Replaceable sealed batteries can extend the usable life of the UPS and reduce whole-unit replacement waste
Warranty Information

Chase Power’s specific warranty period for the Jade 2000 was not published on the manufacturer’s product or catalogue pages. Confirm warranty coverage with Chase Power or the authorised Australian distributor before purchase.

Available Now

Available through Chase Power and authorised Australian distributors, subject to current distributor stock.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
