Jade 3000 3000VA 2100W Line Interactive UPS SNMP Chase Power

BRAND: Chase Power
SKU: CP2336
$1,352.10 List price: $2,028.10
+ −
30 Days Return Electricians Unlock Trade Access
Chase Power Jade 3000 line interactive UPS 3000VA/2100W AVR, ECO mode SNMP-ready. Managed backup for servers and IT.

Alternatively Known As: Jade 3000 UPS, 3000VA UPS, 2100W UPS, Server UPS, SNMP-Ready UPS

Technical Specifications
  • UPS Topology: Line-interactive pure sinewave
  • Capacity: 3000VA / 2100W
  • Nominal Input Voltage: 208/220/230/240VAC
  • Acceptable Input Voltage Range: 162–290VAC
  • Output Voltage: 208/220/230/240VAC
  • Battery Mode Regulation: ±1.5% before battery alarm
  • Output Frequency: 50Hz or 60Hz ±1Hz in battery mode
  • Transfer Time: Typically 2–6ms, maximum 10ms
  • Output Waveform: Pure sinewave
  • Current Crest Ratio: 3:1
  • Harmonic Distortion: Maximum 2% at 100% linear load; maximum 5% at 100% non-linear load
  • Battery Configuration: 4 x 12V/9Ah sealed lead-acid batteries
  • Typical Recharge Time: 4 hours to 90% capacity
  • Efficiency: Greater than 97% in ECO mode; greater than 95% in buck and boost mode
  • Communications: HID-compliant USB and Smart RS-232; optional SNMP/AS400 card
  • Outlets: 8 power-management outlets, including 4 programmable outlets
  • Input Connection: 15A Australian power connection
  • Noise Level: Less than 50dB
  • Operating Environment: 0–40°C; 0–90% RH non-condensing
  • Dimensions (H x L x W): 236mm x 470mm x 145mm
  • Weight: 20.3 kg
Key Features
  • Pure sinewave output for servers, networking equipment and other sensitive electronic loads
  • Automatic buck and boost AVR for voltage stabilisation
  • ECO mode for energy-saving operation
  • Eight power-management outlets with four programmable outlets
  • High-resolution LCD display showing operating and battery status
  • HID-compliant USB interface for Windows, Linux and Mac systems
  • Smart RS-232 communication port and optional SNMP management
  • Emergency Power Off function
  • EMI/RFI noise filtering
  • Three-stage smart battery charging control
  • Full-bridge inverter architecture supports half-wave rectified equipment
Professional Installation Requirements
  • Requires a suitable 15A power point. Connection, circuit suitability and commissioning should be checked by a licensed electrician, particularly where the UPS is deployed in server rooms, telecommunications systems or other critical infrastructure.
Applications
  • Server rooms and IT infrastructure
  • Network storage and networking equipment
  • Telecommunications and PABX systems
  • Computers and business workstations
  • ATM and point-of-sale systems
  • Surveillance and security equipment
  • NBN and internet equipment
  • Medical and electronic equipment
  • Hi-fi and audio equipment
Standards & Compliance
  • AS 62040.1:2019 – applicable Australian safety standard for uninterruptible power systems; product-specific conformity should be confirmed with Chase Power
  • AS IEC 62040.2 – applicable electromagnetic compatibility requirements for UPS equipment
  • AS/NZS 3000 – applicable to the electrical installation, circuit, earthing and 15A supply connection
Environmental Benefits
  • ECO mode can reduce energy consumption during suitable operating conditions
  • High operating efficiency reduces energy losses during operation
  • Replaceable sealed lead-acid batteries can extend product service life and reduce complete-unit replacement
  • Chase Power provides battery replacement, removal, recycling and disposal services
Warranty Information

Chase Power states that its UPS warranty is equal to or superior to comparable brands, but a specific warranty duration for the Jade 3000 is not published on the available product information. Confirm the applicable warranty term and battery coverage with Chase Power or the authorised distributor before purchase.

Available Now

Available through Chase Power and authorised Australian distributors, subject to distributor stock and current product availability.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
