Junction Box Black to Suit Dome Camera Hikvision
Hikvision black dome camera junction box features a junction mounting base for cabling. Ideal for CCTV installs using compatible Hikvision dome cameras.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Hikvision Black Dome Camera Junction Box, DS-1280ZJ-DM8(BLACK), CCTV Camera Junction Mounting Base
Technical Specifications
- Model: DS-1280ZJ-DM8(BLACK)
- Material: Aluminium alloy with surface spray treatment
- Colour: Black
- Junction Type: Dome camera junction box
- Cable Entry: Side and bottom inlets
- Design: Interchangeable bottom waterproof cover and side gland nut
- Maximum Load Capacity: 1 kg
- Installation: Flat wall or ceiling surface
- Outdoor Use: Waterproof rubber gasket required
- Water Resistance: Waterproof design
- Dimensions (H x L x W): 35mm x 126.7mm x 126.7mm
- Weight: 0.21 kg
Key Features
- Provides a secure mounting base for compatible Hikvision dome cameras
- Conceals and protects cable connections
- Black finish for discreet CCTV installations
- Aluminium alloy construction with surface spray treatment
- Side and bottom cable entry options
- Interchangeable bottom waterproof cover and side gland nut
- Suitable for indoor and outdoor camera installations when correctly sealed
- Includes camera and mounting hardware according to the manufacturer’s specification
Applications
- Wall-mounted Hikvision dome camera installations
- Ceiling-mounted Hikvision dome camera installations
- Indoor CCTV systems
- Outdoor CCTV systems with the specified waterproof gasket installed
- Commercial, industrial and residential security camera installations
Standards & Compliance
- AS/NZS 62676.1.1:2020 is relevant to CCTV and video surveillance system requirements; this passive junction box is not separately identified as certified to that standard.
Environmental Benefits
- Aluminium alloy construction is recyclable at end of service life
- Durable metal construction can extend service life and reduce replacement waste
- Protects camera cable connections from environmental exposure when correctly sealed
Warranty Information
Warranty is subject to Hikvision Australia and the authorised distributor’s applicable terms. Hikvision’s extended five-year premium warranty excludes general accessories, so confirm the applicable accessory warranty at purchase.
Available Now
Available through Hikvision and authorised Australian security and electrical distributors.
