Junction Box IP55 80x80x50mm Red MajorTech
MajorTech junction box features IP55 rating and 80x80x50mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETI VJ885R Junction Box, IP55 Electrical Junction Box, Weatherproof Junction Box, ABS Cable Junction Box
Technical Specifications
- Model: VJ885R
- Colour: Red
- Ingress Protection: IP55
- Impact Protection: IK08
- Material: High-quality non-flammable ABS plastic
- Shape: Square
- Cable Entry: 7 stepped rubber glands
- Gland Hole Size: 28 mm
- Operating Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C; maximum 95% relative humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Approvals and Testing: CE, RoHS, HF test, IK test and ISO 9001 manufacturing
- Dimensions (H x L x W): 50mm x 85mm x 85mm
- Weight: 0.1 kg
Key Features
- IP55 protection against dust ingress and water jets
- Seven stepped rubber glands for flexible cable entry
- Rubber glands can be trimmed to suit cable diameter
- IK08 impact resistance for improved mechanical protection
- Non-flammable ABS plastic enclosure
- Suitable for indoor, sheltered outdoor, residential, commercial and industrial electrical connections
Professional Installation Requirements
- Electrical connections and mains wiring should be installed or modified by a licensed electrician in accordance with AS/NZS 3000 and the manufacturer's installation requirements. The IP55 rating depends on correctly fitted glands, covers and cable entries.
Applications
- Indoor electrical cable junctions
- Sheltered outdoor cable connections
- Residential wiring installations
- Commercial and industrial electrical connections
- HVAC, lighting and general electrical cable termination
Standards & Compliance
- AS/NZS 3000:2018 Wiring Rules should be followed for electrical installation, enclosure selection and cable-joint protection. The product documentation specifies IEC 60529 and IEC 60670 rather than an Australian product standard.
Environmental Benefits
- RoHS approval supports restriction of specified hazardous substances in the product
- Durable ABS construction and IK08 impact protection may extend service life and reduce replacement waste
- Plastic enclosure components should be disposed of or recycled according to local ABS and electrical-waste facilities
Warranty Information
5-year limited warranty for the VETI 1 junction-box range, subject to Major Tech warranty terms and conditions.
Available Now
Available through MajorTech and authorised electrical distributors in Australia, subject to distributor stock.
