Junction Box IP55 Round Red MajorTech
MajorTech junction box features IP55 rating and Round 80mm x 50mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi VJ85R Junction Box, IP55 Electrical Junction Box, Round Weatherproof Junction Box
Technical Specifications
- Model: VJ85R
- Colour: Red
- Shape: Round
- Ingress Protection: IP55
- Material: Flame-retardant, self-extinguishing ABS plastic
- Cable Entry: 4 stepped rubber glands
- Gland Hole Size: 28 mm
- Impact Protection: IK08
- Operating Temperature: -5°C to 40°C
- Storage Conditions: Up to 75°C and 95% relative humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals: CE, RoHS, HF test, IK test and ISO 9001
- Dimensions (H x L x W): 50mm x 80mm x 80mm
- Weight: 0.1 kg
Key Features
- IP55 protection against dust ingress and water jets
- Supplied with stepped rubber glands for fast cable entry
- Rubber glands can be removed and replaced with standard compression glands
- Flame-retardant and self-extinguishing ABS construction
- IK08 impact protection
- Suitable for indoor and light outdoor cable connections
- Compact round enclosure for junctions and cable terminations
Professional Installation Requirements
- The enclosure is a passive component, but electrical connections and cable termination should be completed by a licensed electrician in accordance with AS/NZS 3000 and the applicable installation requirements. Confirm that the selected cable glands and installation method maintain the required IP rating.
Applications
- Indoor electrical cable junctions
- Light outdoor cable connections protected from severe exposure
- HVAC, building services and general electrical installations
- Cable branching and termination points
- Residential, commercial and light industrial wiring installations
Standards & Compliance
- AS/NZS IEC 60670.22:2012 is the relevant Australian/New Zealand standard for connecting boxes and enclosures used for junctions and tapping points; manufacturer literature specifies IEC 60670 rather than claiming AS/NZS certification.
- AS/NZS 60529 is relevant to verification and application of the IP55 enclosure rating.
Environmental Benefits
- RoHS approval supports restriction of specified hazardous substances
- Durable ABS enclosure and replaceable rubber glands can reduce replacement frequency and material waste
- Reusable enclosure design supports maintenance and cable reconfiguration rather than complete enclosure replacement
Warranty Information
5-year limited warranty for the VETi IP55/IP65 junction box range, subject to Major Tech warranty terms and exclusions.
Available Now
Available through Major Tech and authorised Australian distributors, subject to distributor stock levels.
