Junction Box IP55 Round Red MajorTech
MajorTech junction box features IP55 rating and Round 55mm x 50mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VJ55R Junction Box, VETi Round Junction Box, IP55 Electrical Junction Box, Weatherproof Cable Junction Box
Technical Specifications
- Model: VJ55R
- Colour: Red
- Ingress Protection: IP55
- Impact Protection: IK08
- Shape: Round
- Material: UV-stabilised, non-flammable ABS plastic
- Cable Entry: Stepped rubber glands
- Gland Hole Size: 28 mm
- Number of Cable Entry Holes: 4
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% relative humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals and Testing: CE, RoHS, HF test, IK test and ISO 9001 manufacturing system
- Dimensions (H x L x W): 50mm x 50mm x 50mm
- Weight: 0.1 kg
Key Features
- IP55 protection against dust ingress and water jets
- Round compact enclosure for cable connections
- Supplied with stepped rubber glands for flexible cable entry
- Rubber glands can be removed and replaced with standard compression glands
- High-quality flame-retardant and self-extinguishing ABS construction
- UV-stabilised material for indoor and sheltered outdoor applications
- IK08 impact resistance rating
- Suitable for residential, commercial and industrial electrical installations
Professional Installation Requirements
- Connection of fixed electrical wiring should be carried out by a licensed electrician in accordance with applicable Australian electrical installation requirements. Ensure cable glands are correctly fitted to maintain the intended IP55 rating.
Applications
- Indoor electrical cable junctions
- Sheltered outdoor cable connections
- Residential wiring installations
- Commercial electrical installations
- Industrial control and wiring connections
- Low-voltage cable branching and termination
Standards & Compliance
- AS/NZS IEC 60670.22:2012 — relevant Australian and New Zealand standard for connecting boxes and enclosures; Major Tech documentation specifies IEC 60670 for this product range.
- AS 60529:2025 — Australian standard for enclosure ingress-protection classifications; the product is manufacturer-rated IP55 to IEC 60529.
Environmental Benefits
- RoHS approval supports restriction of certain hazardous substances in the product
- UV-stabilised ABS construction can extend service life and reduce replacement waste
- ABS plastic may be recyclable subject to local recycling facilities and material-separation requirements
- Flame-retardant enclosure material supports safer, longer-lasting electrical installations
Warranty Information
5-year limited warranty for Major Tech VETi 1 products, subject to the manufacturer’s warranty terms, proof of purchase, registration requirements where applicable and exclusions for misuse, unauthorised alterations, normal wear, electrical surges and corrosion.
Available Now
Available through Major Tech and authorised Australian electrical distributors, subject to distributor stock levels.
