Junction Box IP65 100x100x70mm Red MajorTech
MajorTech junction box features IP65 rating and 100x100x70mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi VJ10107R Junction Box, Weatherproof Junction Box, Electrical Enclosure, IP65 Cable Junction Box
Technical Specifications
- IP Rating: IP65
- Shape: Square
- Colour: Red
- Material: Non-flammable, UV-stabilised ABS plastic
- Rubber Gland Holes: 7
- Stepped Rubber Gland Size: 28mm
- Impact Rating: IK08
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: Up to 75°C, maximum 95% relative humidity
- Manufacturer-Stated Standards: IEC 60529 and IEC 60670
- Manufacturer-Stated Approvals: CE, RoHS, HF test, IK test and ISO 9001 manufacturing
- Dimensions (H x L x W): 70mm x 100mm x 100mm
- Weight: 0.1891 kg
Key Features
- IP65 protection against dust ingress and water jets
- Supplied with rubber stepped glands for cable entry
- Seven cable entry points with 28mm gland openings
- Flame-retardant and self-extinguishing ABS plastic construction
- UV-stabilised enclosure suitable for indoor and outdoor electrical connections
- IK08 impact resistance for protection against mechanical damage
- Rubber glands can be removed and replaced with compatible compression glands
Professional Installation Requirements
- Where used for mains-voltage wiring, installation and termination should be completed by a licensed electrician in accordance with applicable electrical installation requirements, including AS/NZS 3000.
Applications
- Outdoor and indoor cable junctions
- Weather-protected electrical connections
- Residential electrical wiring installations
- Commercial and industrial cable connections
- HVAC, lighting, security and control-system wiring
Standards & Compliance
- AS/NZS IEC 60670.22:2012 is the applicable Australian/New Zealand standard for connecting boxes and enclosures used for junctions and tapping connections.
- AS 60529:2025 is the applicable Australian standard for classification of enclosure ingress protection ratings; the product is manufacturer-rated IP65.
Environmental Benefits
- RoHS compliance limits the use of specified hazardous substances
- UV-stabilised ABS construction can extend service life and reduce replacement waste
- The durable, impact-resistant enclosure helps protect connected electrical components and reduce premature failures
- ABS plastic may be recyclable subject to local recycling facilities and material acceptance
Warranty Information
MajorTech lists a 5-year warranty for the VETi 1 range, subject to the manufacturer's warranty terms and registration requirements where applicable.
Available Now
Available through MajorTech and authorised Australian distributors.
