Junction Box IP65 150x110x70mm Red MajorTech
MajorTech junction box features IP65 rating and 150x110x70mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi Junction Box, Weatherproof Junction Box, Electrical Junction Box, Outdoor Cable Junction Box
Technical Specifications
- Ingress Protection: IP65
- Impact Resistance: IK08
- Shape: Rectangular
- Material: High-quality non-flammable ABS plastic
- Colour: Red
- Cable Entry: Rubber stepped glands
- Gland Hole Size: 28 mm
- Number of Cable Entry Holes: 10
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% relative humidity
- Manufacturer-Listed Standards: IEC 60529 and IEC 60670
- Manufacturer-Listed Approvals and Testing: CE, RoHS, HF test, IK test and ISO 9001 manufacturing quality system
- Dimensions (H x L x W): 70mm x 150mm x 110mm
- Weight: 0.246 kg
Key Features
- IP65 protection against dust ingress and water jets
- Supplied with rubber stepped glands for flexible cable entry
- UV-stabilised ABS enclosure suitable for indoor and outdoor electrical connections
- IK08 impact resistance for improved mechanical protection
- Non-flammable ABS construction with electrical insulation properties
- Rectangular enclosure with ten 28 mm gland entry points
- Suitable for residential, commercial and light industrial installations
Professional Installation Requirements
- Where used for mains or fixed electrical wiring, installation and termination should be performed by a licensed electrician in accordance with AS/NZS 3000 and the manufacturer's installation requirements. Maintain the IP65 seal by correctly fitting the lid, glands and cable entries.
Applications
- Outdoor cable junctions and connections
- Residential electrical wiring installations
- Commercial electrical and building-services installations
- Light industrial control and connection points
- Protection of cable joins from dust, rain and water jets
Standards & Compliance
- AS/NZS 60529: Relevant Australian/New Zealand standard for degrees of protection provided by electrical enclosures and IP ratings
- AS/NZS IEC 60670.22: Relevant requirements for connecting boxes and enclosures used for electrical junctions and tapping points
Environmental Benefits
- UV-stabilised ABS construction can extend enclosure service life and reduce replacement waste
- RoHS-listed construction supports reduced use of restricted hazardous substances
- Durable, reusable enclosure protects internal electrical components and may reduce maintenance-related material waste
Warranty Information
MajorTech's published warranty policy lists distribution boards and enclosures with a 5-year warranty, subject to the applicable warranty terms, proof of purchase and exclusions for misuse, unauthorised modification, corrosion and inadequate maintenance.
Available Now
Available through MajorTech and authorised Australian electrical and trade distributors.
