Junction Box IP65 200x155x80mm Red MajorTech
MajorTech junction box features IP65 rating and 200x155x80mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi VJ20158R Junction Box, Weatherproof Junction Box, ABS Electrical Enclosure, Cable Junction Box
Technical Specifications
- Ingress Protection: IP65
- Impact Protection: IK08
- Material: Non-flammable, UV-stabilised ABS plastic
- Shape: Rectangular
- Cable Entry: 10 stepped rubber gland holes
- Gland Hole Size: 36mm
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% humidity
- Colour: Red
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals: CE, RoHS, HF test, IK test and ISO 9001 manufacturing
- Dimensions (H x L x W): 80mm x 200mm x 155mm
- Weight: 0.35 kg
Key Features
- IP65 protection against dust ingress and water jets
- Supplied with stepped rubber glands for flexible cable entry
- UV-stabilised ABS enclosure suitable for indoor and outdoor applications
- IK08 impact resistance for improved mechanical protection
- Non-flammable enclosure material
- Suitable for residential, commercial and industrial electrical connections
Professional Installation Requirements
- Electrical connections and fixed wiring should be installed by a licensed electrician in accordance with AS/NZS 3000 and applicable local requirements. Ensure cable glands are correctly fitted to maintain the IP65 rating.
Applications
- Weatherproof cable junctions
- Indoor and outdoor electrical connections
- Residential wiring installations
- Commercial electrical enclosures
- Industrial cable management and equipment connections
Standards & Compliance
- IEC 60529 is aligned with the Australian and New Zealand IP enclosure standard AS/NZS 60529
- IEC 60670 is relevant to the Australian and New Zealand enclosure standard series AS/NZS IEC 60670, including AS/NZS IEC 60670.22:2012 for connecting boxes and enclosures
Environmental Benefits
- UV-stabilised ABS construction can extend service life and reduce replacement waste
- RoHS approval supports reduced use of restricted hazardous substances
- The ABS enclosure is potentially recyclable through suitable plastics recycling channels at end of life
Warranty Information
Limited 5-year warranty for the VETi IP55 and IP65 junction box range, subject to MajorTech warranty terms and conditions.
Available Now
Available through MajorTech and authorised Australian electrical distributors, subject to distributor stock.
