Junction Box IP65 255x200x80mm Red MajorTech
MajorTech junction box features IP65 rating and 255x200x80mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: IP65 Electrical Junction Box, Weatherproof Junction Box, ABS Cable Connection Box, VETi VJ25208R
Technical Specifications
- Model: VJ25208R
- Colour: Red
- Ingress Protection: IP65
- Impact Protection: IK08
- Material: Non-flammable, UV-stabilised ABS plastic
- Shape: Rectangular
- Cable Entry: 12 rubber stepped gland openings
- Stepped Rubber Gland Hole Size: 36 mm
- Operating Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% humidity
- Manufacturer-Stated Standards: IEC 60529 and IEC 60670
- Manufacturer-Stated Approvals and Testing: CE, RoHS, HF test, IK test and ISO 9001
- Dimensions (H x L x W): 80mm x 255mm x 200mm
- Weight: 0.53 kg
Key Features
- IP65 protection against dust ingress and water jets when correctly assembled
- UV-stabilised ABS enclosure suitable for indoor and outdoor electrical connections
- Supplied with rubber stepped glands for flexible cable entry
- IK08 impact resistance for protection against mechanical impacts
- Non-flammable ABS construction provides electrical insulation
- Twelve 36 mm stepped rubber gland entry points
- Suitable for residential, commercial and industrial applications
Professional Installation Requirements
- Where used for mains-voltage wiring, installation and cable termination should be performed by a licensed electrician in accordance with AS/NZS 3000. Cable glands, seals and cover fasteners must be correctly installed to maintain the IP65 rating.
Applications
- Indoor electrical cable junctions
- Outdoor and weather-exposed cable connections
- Residential electrical installations
- Commercial and industrial wiring enclosures
- HVAC, refrigeration and control-system cable terminations
- Protection of terminal blocks, cable joins and small electrical components
Standards & Compliance
- AS/NZS 60529: Relevant Australian/New Zealand standard for enclosure ingress-protection ratings; the manufacturer states IEC 60529 for the product IP65 rating.
- AS/NZS IEC 60670.22:2012: Relevant requirements for connecting boxes and enclosures used for junctions and tappings; the manufacturer states IEC 60670 for this product.
- AS/NZS 3000:2018: Applicable to selection, installation and wiring practices when the enclosure is used within an Australian electrical installation.
Environmental Benefits
- UV-stabilised ABS construction is designed to extend service life and reduce replacement waste
- RoHS approval indicates restriction of specified hazardous substances in the product
- Durable enclosure construction supports repeated use in demanding indoor and outdoor installations
- ABS plastic components may be recyclable subject to local recycling facilities and material-separation requirements
Warranty Information
Limited 5-year warranty for the VETi IP55/IP65 junction-box range, subject to MajorTech warranty terms and conditions. ([major-tech.com](https://www.major-tech.com/uploads/media_uploads/2/VETi%20Catalogue%20Australia.pdf?utm_source=openai))
Available Now
Available through MajorTech and authorised Australian electrical distributors; confirm current distributor stock before ordering.
