Junction Box IP65 300x250x120mm Red MajorTech
MajorTech junction box features IP65 rating and 300x250x120mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi VJ302512R Junction Box, Weatherproof Junction Box, ABS Electrical Enclosure, Cable Junction Box
Technical Specifications
- Ingress Protection: IP65
- Impact Protection: IK08
- Material: UV-stabilised, non-flammable ABS plastic
- Shape: Rectangular
- Cable Entry: 12 rubber stepped gland holes
- Gland Hole Size: 36 mm
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals: CE, RoHS, HF test, IK test and ISO 9001
- Carton Quantity: 20 units
- Dimensions (H x L x W): 120mm x 300mm x 250mm
- Weight: 1.2 kg
Key Features
- IP65 protection against dust ingress and water jets when correctly installed
- Supplied with rubber stepped glands for secure cable entry
- UV-stabilised ABS enclosure suitable for indoor and outdoor electrical connections
- IK08 impact resistance for improved mechanical protection
- Non-flammable enclosure material
- Red finish for easy identification
- Suitable for residential, commercial and industrial cable junctions
Professional Installation Requirements
- Electrical wiring and cable termination should be completed by a licensed electrician in accordance with applicable Australian electrical installation requirements. Cable glands, seals and enclosure entries must be correctly installed to maintain the IP65 rating.
Applications
- Outdoor and indoor cable junctions
- Electrical cable terminations
- Industrial control and automation wiring
- Commercial building services
- Weather-exposed electrical connections
- General-purpose cable management and protection
Standards & Compliance
- AS/NZS IEC 60670.22:2012 — applicable Australian/New Zealand standard for connecting boxes and enclosures used for junctions and tappings; manufacturer specifies IEC 60670
- AS/NZS 60529 — Australian/New Zealand adoption of the enclosure ingress protection classification standard; manufacturer specifies IEC 60529
- AS/NZS 3000 — relevant to the installation of the enclosure within Australian electrical installations
Environmental Benefits
- RoHS approval supports restriction of hazardous substances in the product
- UV-stabilised ABS construction can extend service life and reduce replacement waste
- Durable, impact-resistant enclosure helps protect installed electrical components and prolong system lifespan
- ABS plastic may be recyclable subject to local recycling facilities and material separation
Warranty Information
5-year limited warranty for the VETi junction box range, subject to Major Tech warranty terms and conditions.
Available Now
Available through Major Tech and authorised Australian electrical distributors.
