Junction Box IP65 400x350x120mm Red MajorTech
MajorTech junction box features IP65 rating and 400x350x120mm dimensions in red. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi IP65 Junction Box, Weatherproof Electrical Enclosure, ABS Cable Junction Box, Outdoor Junction Box
Technical Specifications
- Model: VJ403512R
- Colour: Red
- Ingress Protection: IP65
- Impact Protection: IK08
- Shape: Rectangular
- Material: UV-stabilised ABS plastic
- Material Performance: Non-flammable
- Cable Entries: 16
- Stepped Rubber Gland Hole Size: 36 mm
- Operating Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals and Testing: CE, RoHS, HF test, IK test and ISO 9001
- Dimensions (H x L x W): 120mm x 400mm x 350mm
- Weight: 1.8 kg
Key Features
- IP65 protection against dust ingress and water jets
- Supplied with stepped rubber glands for cable entry
- Sixteen 36 mm cable entry positions
- IK08 impact resistance for demanding installation environments
- UV-stabilised ABS plastic enclosure
- Non-flammable enclosure construction
- Suitable for indoor and outdoor electrical connection protection
- Rubber glands can be removed and replaced with standard compression glands
Professional Installation Requirements
- Electrical connections and installation in fixed wiring systems should be completed by a licensed electrician in accordance with applicable Australian wiring requirements, including AS/NZS 3000. Maintain the enclosure's IP rating by correctly fitting and sealing all cable entries.
Applications
- Outdoor electrical cable junctions
- Industrial and commercial wiring installations
- Weather-protected cable connections
- Control panels and low-voltage electrical enclosures
- Building services and facilities maintenance installations
Standards & Compliance
- AS/NZS 60529:2025 is the Australian standard for degrees of protection provided by enclosures and corresponds to the product's stated IEC 60529 IP classification
- AS/NZS 60670.1:2021 provides applicable general requirements for boxes and enclosures for electrical accessories
- AS/NZS IEC 60670.22:2012 covers particular requirements for connecting boxes and enclosures
Environmental Benefits
- RoHS approval helps restrict specified hazardous substances
- UV-stabilised construction can extend service life and reduce replacement waste
- Durable ABS enclosure helps protect electrical equipment and reduce premature component failure
- Plastic enclosure components may be recyclable subject to local recycling facilities
Warranty Information
Five-year limited warranty, as specified by MajorTech for the VETi junction box range.
Available Now
Available through MajorTech and authorised Australian electrical distributors, subject to distributor stock.
