Laser Distance Sensor DL35-B15552 | 200 mm to 35,000 mm Range | 0.1 mm Resolution | IP65 & IP67 Rated | by SICK
The Laser Distance Sensor DL35-B15552 offers a measuring range from 200 mm to 35,000 mm, making it perfect for industrial automation and precise distance measurement. With a high resolution of 0.1 mm and robust IP65/IP67 enclosure, it ensures reliable performance in harsh environments. Ideal for applications in material handling, quality control, and robotics, this sensor is designed for efficiency and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 200 mm to 35,000 mm on diamond grade reflective tape
- Resolution: 0.1 mm
- Repeatability: ≥ 0.5 mm
- Measurement accuracy: Typically ± 15 mm
- Response time: 2.5 ms to 96.5 ms selectable
- Switching frequency: Up to 333 Hz
- Output time: 1 ms to 32 ms selectable
- Light source: Red laser, visible light
- Laser class: 1 (IEC 60825-1:2014 compliant)
- Supply voltage: DC 12 V to 30 V
- Power consumption: ≤ 1.7 W
- Enclosure rating: IP65 and IP67
- Operating temperature: -30 °C to +55 °C
- Connection type: Male connector
- Display: LEDs
- Dimensions (H x L x W): 58.67mm x 42.7mm x 32mm
- Weight: 0.1 kg
Key Features
- Measuring range from 200 mm to 35,000 mm on diamond grade reflective tape
- High resolution of 0.1 mm and repeatability ≥ 0.5 mm
- Fast response time adjustable from 2.5 ms to 96.5 ms
- Multiple output modes including current, voltage, and digital outputs
- Laser class 1 with visible red light and 100,000 hours average laser service life
- Robust IP65 and IP67 rated enclosure for harsh environments
- Wide operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for precise distance measurement
- Material handling and logistics for object detection
- Quality control and inspection systems
- Robotics and machine safety systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption of ≤ 1.7 W reduces energy usage
- Long laser service life of 100,000 hours minimizes waste and replacement frequency
- Robust design reduces environmental impact through durability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK DL35-B15552 Laser Distance Sensor is available for immediate purchase, ideal for industrial automation and precision measurement applications.
