Laser Distance Sensor DL35-B15852 | 200 mm to 35,000 mm Range | 0.1 mm Resolution | IP65 & IP67 Rated | by SICK
The Laser Distance Sensor DL35-B15852 offers a measuring range from 200 mm to 35,000 mm, making it perfect for industrial automation and precise distance measurement. With a high resolution of 0.1 mm and fast response times, this sensor is designed for object detection and quality control in manufacturing environments. Its robust IP65 and IP67 rated enclosure ensures durability in challenging conditions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 200 mm to 35,000 mm on diamond grade reflective tape
- Resolution: 0.1 mm
- Repeatability: ≥ 0.5 mm
- Measurement accuracy: Typical ± 15 mm
- Response time: 2.5 ms to 96.5 ms selectable
- Switching frequency: Up to 333 Hz
- Output time: 1 ms to 32 ms selectable
- Light source: Infrared laser, Class 1
- Typical light spot size: 15 mm x 15 mm at 2 m
- Supply voltage: DC 12 V to 30 V
- Power consumption: ≤ 1.7 W
- Enclosure rating: IP65, IP67
- Protection class: III
- Connection type: Male connector
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +75 °C
- EMC standards: EN 61000-6-2, EN 61000-6-3, EN 61000-6-4
- Dimensions (H x L x W): 58.67mm x 42.7mm x 32mm
- Weight: 0.1 kg
Key Features
- Measuring range from 200 mm to 35,000 mm on diamond grade reflective tape
- High resolution of 0.1 mm and repeatability ≥ 0.5 mm
- Fast response time options from 2.5 ms to 96.5 ms
- Infrared laser light source with a typical spot size of 15 mm x 15 mm at 2 m
- Laser class 1 with 100,000 hours average laser service life
- Multiple output options including current, voltage, and digital outputs
- IP65 and IP67 rated enclosure for robust protection
- Wide operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for precise distance measurement
- Object detection and positioning in manufacturing
- Quality control and process monitoring
Standards & Compliance
- Complies with AS/NZS 61000 series for Electromagnetic Compatibility (EMC) standards
Environmental Benefits
- Low power consumption of ≤ 1.7 W reduces energy usage
- Long laser service life of 100,000 hours minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK DL35-B15852 Laser Distance Sensor is available for immediate purchase, ideal for industrial automation and precision measurement applications.
