Laser Distance Sensor DR35-B15822 | 200 mm to 35,000 mm Range | 0.1 mm Resolution | IP65 & IP67 Rated | by SICK
The Laser Distance Sensor DR35-B15822 offers a measuring range from 200 mm to 35,000 mm, making it perfect for industrial automation and precise distance measurement. With a high resolution of 0.1 mm and robust IP65/IP67 enclosure, it ensures reliable performance in harsh environments. Ideal for applications in object detection, quality control, and robotics, this sensor is designed for efficiency and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 200 mm to 35,000 mm on diamond grade reflective tape
- Resolution: 0.1 mm
- Repeatability: ≥ 0.5 mm
- Measurement accuracy: Typically ± 15 mm
- Response time: 2.5 ms to 96.5 ms selectable
- Switching frequency: Up to 333 Hz
- Output time: 1 ms to 32 ms selectable
- Light source: Laser, infrared, class 1
- Light spot size: 15 mm x 15 mm at 2 m
- Supply voltage: DC 12 V to 30 V
- Power consumption: ≤ 1.7 W
- Enclosure rating: IP65 and IP67
- Operating temperature: -30 °C to +55 °C
- Connection type: Male connector
- Digital outputs: 2 push-pull (PNP/NPN), max 100 mA
- IO-Link V1.1 interface with 38.4 kbit/s data rate
- Dimensions (H x L x W): 58.67mm x 42.7mm x 32mm
- Weight: 0.1 kg
Key Features
- Measuring range from 200 mm to 35,000 mm on diamond grade reflective tape
- High resolution of 0.1 mm and repeatability ≥ 0.5 mm
- Measurement accuracy typically ± 15 mm
- Fast response time selectable from 2.5 ms to 96.5 ms
- Laser class 1 infrared light source with 100,000 hours average service life
- Multiple switching modes including distance to reflective tape and switching window
- IO-Link V1.1 interface for process data, parameterization, and diagnosis
- Push-pull digital outputs (PNP/NPN) with max output current ≤ 100 mA
- Robust IP65 and IP67 rated enclosure for harsh environments
- Wide operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial automation for precise distance measurement
- Object detection and positioning in manufacturing
- Quality control and process monitoring
- Robotics and material handling systems
Standards & Compliance
- Complies with AS/NZS 61000 series for Electromagnetic Compatibility (EMC)
Environmental Benefits
- Low power consumption of ≤ 1.7 W reduces energy usage
- Long laser service life of 100,000 hours minimizes waste and replacement frequency
- Robust design reduces environmental impact through durability and reliability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK DR35-B15822 Laser Distance Sensor is available for immediate purchase, ideal for industrial automation and precision measurement applications.
