Laser Distance Sensor DT50-P1114 | 200 mm to 10,000 mm Range | 1 mm Resolution | IP65 Rated | by SICK
The Laser Distance Sensor DT50-P1114 offers a measuring range from 200 mm to 10,000 mm, making it perfect for industrial automation and precise distance measurement. With a high resolution of 1 mm and a fast response time of 20 ms to 30 ms, this sensor is designed for object detection and quality control in manufacturing environments. Its IP65 rated enclosure ensures durability against dust and water, making it a reliable choice for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Laser Distance Sensor DT50-P1114 | 200 mm to 10,000 mm Range | 1 mm Resolution | IP65 Rated | by SICK
Brand: SICK
SKU: 1047581
Alternatively Known As: Laser Distance Sensor DT50, SICK DT50 Laser Sensor, Industrial Laser Rangefinder
Technical Specifications
- Measuring range: 200 mm to 10,000 mm (90% remission), 200 mm to 6,500 mm (18% reflection), 200 mm to 4,000 mm (6% remission)
- Resolution: 1 mm
- Repeatability: ≥ 2.5 mm
- Measurement accuracy: ± 10 mm
- Response time: 20 ms to 30 ms
- Output time: ≥ 4 ms
- Light source: Visible red laser, class 2 (IEC 60825-1:2014)
- Typical light spot size at 10 m: 15 mm x 15 mm
- Digital output: 1 PNP voltage output, max 100 mA
- Analog output: 0 V to 10 V, 16 bit resolution
- Supply voltage: DC 15 V to 30 V
- Power consumption: ≤ 2.1 W
- Enclosure rating: IP65
- Protection class: III
- Operating temperature: -30 °C to +65 °C (up to +140 °C with cooling plates and filter)
- Weight: 200 g
- Connection: Male M12, 5-pin connector
- Dimensions (H x L x W): 63mm x 58mm x 36mm
- Weight: 0.2 kg
Key Features
- Measuring range from 200 mm to 10,000 mm depending on remission factor
- High resolution of 1 mm and repeatability ≥ 2.5 mm
- Fast response time between 20 ms and 30 ms
- Visible red laser light source with laser class 2
- Multifunctional input for laser off, external teach, or deactivation
- IP65 rated enclosure for protection against dust and water
- Metal zinc diecast housing with plastic (PMMA) window
- LC display with 2 LEDs for status indication
- Operating temperature range from -30 °C to +65 °C (up to +140 °C with cooling plates and protection filter)
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with laser safety and electrical wiring standards to ensure proper setup and compliance.
Applications
- Industrial automation for precise distance measurement
- Object detection and positioning in manufacturing
- Quality control and process monitoring
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption of ≤ 2.1 W reduces energy usage
- Long laser service life of 100,000 hours minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK DT50-P1114 Laser Distance Sensor is available for immediate purchase, ideal for industrial automation and precise measurement applications.
