Laser Distance Sensor SICK DS35-B15821 | 50 mm to 12,000 mm Range | 0.1 mm Resolution | IP65/IP67 Rated | by SICK
The Laser Distance Sensor SICK DS35-B15821 offers a measuring range from 50 mm to 12,000 mm, with a high resolution of 0.1 mm and repeatability of ≥ 0.5 mm. Ideal for industrial automation, this sensor is perfect for precise distance measurement, object detection, and quality control. With a robust IP65/IP67 rated enclosure, it operates effectively in harsh environments, ensuring reliability and accuracy in your applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 50 mm to 12,000 mm (90% remission factor)
- Resolution: 0.1 mm
- Repeatability: ≥ 0.5 mm
- Measurement accuracy: Typically ±10 mm
- Response time: 2.5 ms to 96.5 ms selectable
- Switching frequency: Up to 333 Hz
- Output time: 1 ms to 32 ms selectable
- Light source: Infrared laser, laser class 1
- Laser service life: 100,000 hours at 25 °C
- Supply voltage: DC 12 V to 30 V
- Power consumption: ≤ 1.7 W
- Enclosure rating: IP65, IP67
- Protection class: III
- Connection type: Male connector
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +75 °C
- EMC standards: EN 61000-6-2, EN 61000-6-3, EN 61000-6-4
- Dimensions (H x L x W): 58.67mm x 42.7mm x 32mm
- Weight: 0.1 kg
Key Features
- Measuring range from 50 mm to 12,000 mm depending on remission factor
- High resolution of 0.1 mm and repeatability ≥ 0.5 mm
- Fast response time adjustable from 2.5 ms to 96.5 ms
- Infrared laser light source with laser class 1 safety
- Multifunctional input and adaptable digital outputs
- Robust IP65 and IP67 rated enclosure for harsh environments
- Wide operating temperature range from -30 °C to +55 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for precise distance measurement
- Object detection and positioning in manufacturing
- Quality control and process monitoring
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption of ≤ 1.7 W reduces energy usage
- Long laser service life of 100,000 hours minimizes waste
- Robust design reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK DS35-B15821 Laser Distance Sensor is available for immediate purchase, ideal for industrial automation and precise measurement applications.
