Latch Contactor 150A AC3 | Electromagnetic Latch Mechanism | Heavy-Duty Industrial Use | @Pack of 1 | by Clipsal
The Latch Contactor 150A AC3 is designed for reliable industrial motor control and power distribution. With a high current capacity of 150A AC3 and 250A AC1, it features an electromagnetic latch mechanism for dependable operation. Ideal for heavy-duty applications, this contactor ensures efficient energy management and reduced power consumption, making it perfect for HVAC systems and commercial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Latch Contactor 150A AC3 | Electromagnetic Latch Mechanism | Heavy-Duty Industrial Use | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHCR1F185M7
Alternatively Known As: industrial contactor, power contactor, latch relay, heavy duty contactor, SCHCR1F185M7
Technical Specifications
- Rated operational current: 150A (AC3), 250A (AC1)
- Coil voltage: 220-240V AC (other voltages available on request)
- Number of poles: 3
- Utilization category: AC3/AC1
- Mechanical endurance: 10 million operations
- Electrical endurance: 1 million operations (AC3)
- Mounting: DIN rail or panel mounting
- Auxiliary contacts: Optional
- Operating temperature: -25°C to +60°C
- Degree of protection: IP20
- Dimensions (H x L x W): 160mm x 140mm x 105mm
- Weight: 2.5 kg
Key Features
- High current capacity: 150A AC3/250A
- Electromagnetic latch mechanism for reliable operation
- Suitable for heavy-duty industrial applications
- Robust construction for long service life
- Low power consumption holding circuit
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Power distribution panels
- Commercial and industrial automation
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient energy management by providing reliable load control
- Reduces unnecessary power consumption through secure latching operation
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Latch Contactor 150A AC3/250A (SCHCR1F185M7) is available for immediate purchase. Ideal for industrial and commercial motor control and power distribution applications.
