Trade Discount 20%
Latch Contactor 500A AC3/700A | Magnetic Latching | 3 Poles | 110V DC Coil | @Pack of 1 | by Clipsal
The Latch Contactor 500A AC3/700A is designed for industrial motor control and heavy machinery switching, featuring a magnetic latching mechanism for energy efficiency and reliable operation. With a robust 3-pole configuration and a 110V DC control coil, this contactor is perfect for demanding environments, ensuring high electrical and mechanical endurance for your power distribution needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Latch Contactor 500A AC3/700A | Magnetic Latching | 3 Poles | 110V DC Coil | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHCR1F500F7
Alternatively Known As: 500A Latching Contactor, Magnetic Latching Contactor 500A, TeSys F 500A Contactor, Industrial Power Contactor, Clipsal SCHCR1F500F7
Technical Specifications
- Rated operational current: 500A (AC-3, ≤440V)
- Rated operational current: 700A (AC-1)
- Number of poles: 3 (3NO)
- Control voltage: 110V DC coil
- Utilization category: AC-3/AC-1
- TeSys F series
- High electrical and mechanical endurance
- Suitable for heavy-duty industrial applications
- Dimensions (H x L x W): 340mm x 250mm x 320mm
- Weight: 18 kg
Key Features
- Magnetic latching contactor for energy saving and reliable operation
- Rated for 500A AC-3 (up to 440V) and 700A AC-1 applications
- 3 poles (3NO) configuration
- 110V DC coil for control circuit
- TeSys F series robust design for demanding environments
- High electrical and mechanical endurance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and relevant local regulations.
Applications
- Industrial motor control
- Heavy machinery switching
- Power distribution panels
- HVAC systems
- Pumping stations
- Large commercial and industrial electrical installations
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Magnetic latching reduces coil power consumption, lowering energy usage
- Durable construction extends product lifespan, reducing replacement waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Latch Contactor 500A AC3/700A SCHCR1F500F7 is available for immediate purchase. Ideal for industrial and commercial power control applications.
