LED Driver 100W 12V DC Constant Voltage IP20 Dimmable Domus
Domus 100W 12V DC constant voltage LED driver, IP20, dimmable, suits 12V constant voltage LED strip and fittings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 100W 12V LED Driver, 12V Constant Voltage LED Power Supply, Triac Dimmable LED Driver
Technical Specifications
- Input Voltage: 240V AC
- Output Voltage: 12V DC constant voltage
- Rated Power: 100W
- Output Current: 8.33A
- Dimming: Triac dimmable with a compatible dimmer
- IP Rating: IP20
- Efficiency: Up to 89%
- Power Factor: Greater than 0.95
- Flicker Performance: Flicker-free when installed less than 2m from the light source
- Connection: Supplied with 1m flex and plug
- Wiring: Parallel wiring
- Protection: Short circuit, thermal overload, over-temperature and over-voltage protection
- Dimensions (H x L x W): 30mm x 189mm x 65mm
- Weight: 0.5 kg
Key Features
- Designed for 12V constant voltage LED strips and fittings
- Suitable for indoor LED lighting applications
- Triac dimmable with compatible dimmers
- IP20-rated housing for indoor use only
- Built-in electrical and thermal protection
- Supplied with 1m flex and plug
- Suitable for parallel wiring
- Suitable for LED strips, inground uplighters, garden spike lights and general LED lighting
- Flicker-free operation when installed within the specified distance from the light source
Professional Installation Requirements
- Installation and connection to 240V mains wiring must be carried out by a licensed electrician in accordance with applicable Australian electrical installation requirements. Use only with compatible dimmers and indoor installations.
Applications
- 12V constant voltage LED strip lighting
- Indoor architectural and decorative lighting
- Inground uplighters
- Garden spike lighting
- Low-voltage LED fittings
- Residential and commercial indoor lighting systems
Standards & Compliance
- AS/NZS 61347.1:2016 – applicable general and safety requirements for lamp controlgear
- AS/NZS IEC 61347.2.13:2013 – relevant particular requirements for electronic controlgear for LED modules
- AS/NZS 3000 – applicable requirements for the electrical installation and 240V mains connection
- AS/NZS 4417.1 – relevant Regulatory Compliance Mark requirements where applicable
Environmental Benefits
- Supports energy-efficient LED lighting systems with up to 89% driver efficiency
- Constant-voltage operation allows one driver to supply compatible 12V LED strips and fittings in parallel
- Replaceable driver design can extend the service life of the connected LED lighting system and reduce replacement waste
Warranty Information
Domus product information states a 5-year replacement warranty for the DRIVER-IP20-DIM series. Warranty coverage is subject to Domus terms, correct installation and use by a licensed electrician.
Available Now
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting distributors.
