Home/Electrical/Lighting/Light Fittings/Battens/LED Linear Batten 30W | 5000lm | Dimmable & Linkable | Opal White by SAL

Trade Discount 4%

LED Linear Batten 30W | 5000lm | Dimmable & Linkable | Opal White by SAL

BRAND: SAL

SKU: SL9775TC/DF5

$32.30 List price: $33.50

+ −

30 Days Return Delivery Options

LED linear batten with 30W power and 5000lm output—ideal for decorative commercial spaces and meeting rooms. Built for versatility, with dimmable and linkable features, and opal white finish.

Description
Attachments

Product Name/Title: PHOENIX SL9775TC - OPAL WHITE

Brand: SAL

SKU: SL9775TC/DF5

Colour: OPAL

Alternatively Known As: LED Linear Batten, Dimmable LED Light, Linkable LED Fixture

Technical Specifications

Power: 30W
Input Voltage: 220-240V
Lumens Output: 5000lm
CRI: > 80
Dimmable: Yes, 1-10V
Body Colour: Opal White
Dimensions (H x L x W): 50mm x 1800mm x 75mm
Weight: 1.5 kg

Key Features

30W LED linkable with 1-10V dimmable functionality
Selectable CCT: 3000K, 4000K, 5700K
Extruded rectangular aluminium profile
Opal polycarbonate diffuser
High efficiency LED optics with CRI > 80
Surface mount or suspended installation

Professional Installation Requirements

Professional installation is recommended for optimal performance and safety.

Applications

Decorative commercial service spaces
Meeting rooms
Amenity areas

Standards & Compliance

Complies with AS/NZS 3000 for electrical installation safety.

Environmental Benefits

Energy-efficient design reduces power consumption.

Warranty Information

2 years warranty against manufacturing defects.

Available Now

The PHOENIX SL9775TC - OPAL WHITE is available now for immediate purchase. Ideal for decorative commercial spaces and meeting rooms.

Installation Sheets (PHOENIX_SL9775TC_installation.pdf, 1,217 Kb) [Download]

Data Sheet (18457-c947fdc9446f7411e834364c0ff1a242.pdf, 507 Kb) [Download]

SDOC Files (DECLARATION_OF_CONFORMITY_PHOENIX_II.pdf, 247 Kb) [Download]

Lighting Requirement Calculator

Room Length (m):

Room Width (m):

Room Height (m):
Select Room Type:
Beam Angle (degrees):
Kelvin Rating:
Enter Lumens per Light:

This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
