LED Safety Sensor L41S-33MA2A | Visible Red Light | 84m Scanning Range | IP67 Rated | by SICK
The LED Safety Sensor L41S-33MA2A features a visible red light source with a 660 nm wavelength and a scanning range of up to 84 meters. Designed for industrial safety monitoring and machine guarding, this sensor boasts a fast response time of 0.2 ms and a robust cylindrical design with nickel-plated brass housing. With an IP67 rating, it ensures reliable performance in harsh environments, making it ideal for automation systems requiring high safety integrity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Safety sensor, LED safety sensor, red light safety sensor, cylindrical safety sensor, industrial safety sensor
Technical Specifications
- Light source: LED
- Type of light: Visible red light (660 nm)
- Scanning range: 84 m
- Number of beams: 1
- Detection capability: 30 mm
- Optical axis: Axial
- Response time: 0.2 ms + test device response time
- Safety type: Type 4 (IEC 61496-1)
- Safety integrity level: SIL 3 (IEC 61508)
- Category: Category 4 (EN ISO 13849)
- Performance level: PL e (EN ISO 13849)
- PFHD: 8.1 x 10^-10 (EN ISO 13849)
- Mission time: 20 years (EN ISO 13849)
- Connection type: Male connector M12, 4-pin, angled
- Display elements: LED
- Protection class: III (IEC 61140)
- Power consumption: 20 mA
- Design: Cylindrical
- Housing material: Nickel-plated brass
- Front screen material: Glass
- Enclosure rating: IP67 (EN 60529)
- Operating temperature: -40 °C to +55 °C
- Storage temperature: -40 °C to +75 °C
- Air humidity: 15% to 95%, non-condensing
- Vibration resistance: 5 g, 10 Hz to 55 Hz (IEC 60068-2-6)
- Shock resistance: 10 g, 16 ms (IEC 60068-2-27)
- Aperture angle/receiving angle: ± 2.5° / ± 2.5°
- Dimensions (H x L x W): 30mm x 100mm x 30mm
- Weight: 0.212 kg
Key Features
- Visible red LED light source with 660 nm wavelength
- Single beam with scanning range up to 84 m
- High detection capability of 30 mm
- Axial optical axis design
- Fast response time of 0.2 ms plus test device response time
- Robust cylindrical design with nickel-plated brass housing
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40 °C to +55 °C
- Vibration and shock resistant
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety sensor systems and compliance with relevant safety standards.
Applications
- Industrial safety monitoring
- Machine guarding
- Automation systems requiring high safety integrity
- Hazardous area detection
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption of 20 mA reduces energy usage
- Durable materials and robust design extend product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK L41S-33MA2A safety sensor is available for immediate purchase, ideal for industrial safety and automation applications.
