Ledfire Advanced Surface Mount IP65 DALI | Black Finish | 90 Min Emergency Duration | 320 Lumen Output | by Ektor
The Ledfire Advanced Surface Mount IP65 DALI Emergency Light is designed for commercial and industrial applications, featuring a robust IP65 rating for dust and water protection. With a powerful 320 lumen output and a 90-minute emergency duration, this light ensures safety during power outages. Its integrated DALI DT1 emergency driver supports wireless monitoring, making it an ideal choice for modern emergency lighting systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: IP65 Emergency Surface Mount Light, DALI Emergency Light, Wireless Emergency LED Light, Ledfire Surface Emergency Light
Technical Specifications
- IP Rating: IP65
- Body Material: Polycarbonate
- Installation Type: Surface mount
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Frequency: 50 Hz
- Maximum Wattage: 2 W
- Standby Power: 0.4 W
- Driver Type: DALI DT1 Emergency with wireless IEC62386-104 support
- Emergency Mode: Non-Maintained
- Emergency Classification: C0:D63, C90:D63
- Emergency Output Power: 2200 mW
- Emergency Duration: 90 minutes
- Emergency Lumen Output: 320 lm
- Operating Temperature Range: 0 to 40 °C
- Wiring Type: Re-wireable terminal block (3 or 5 pin depending on model)
- Product Design Life: 8 years
- Dimensions (H x L x W): 50mm x 150mm x 150mm
- Weight: 0.5 kg
Key Features
- IP65 rated for dust and water ingress protection
- Surface mount installation with polycarbonate body
- Integrated DALI DT1 emergency driver with wireless IEC62386-104 support
- Non-maintained emergency mode with 90 minutes duration
- Emergency output power of 2200 mW and lumen output of 320 lm
- Supports emergency test and monitoring over DALI and wireless protocols
- Operating temperature range from 0 to 40 °C
- Low standby power consumption of 0.4 W
- Product design life of 8 years
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure compliance with electrical and emergency lighting standards.
Applications
- Commercial and industrial emergency lighting
- Surface mount installations requiring IP65 rated emergency lighting
- Areas requiring DALI monitored emergency lighting systems
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for Emergency Lighting
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance
- AS/NZS 2293.3 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Low power consumption reduces energy usage during standby and operation
- Long product design life minimizes waste and replacement frequency
- Supports wireless and DALI monitoring to optimize maintenance and reduce unnecessary battery replacements
Warranty Information
6 years return to base (RTB) commercial use warranty.
Available Now
The Ledfire Advanced Surface Mount IP65 DALI Emergency Light is available for immediate purchase, ideal for commercial and industrial emergency lighting applications.
