Ledfire Core Emergency Luminaire Black | IP44 Rated | Non-Maintained Mode | 90 Min Emergency Duration | by Ektor
The Ledfire Core Emergency Luminaire Black is designed for reliable emergency lighting in commercial and public spaces. With an IP44 rating for moisture resistance and a non-maintained mode providing 90 minutes of emergency duration, this recessed luminaire ensures safety and compliance. Built with a durable polycarbonate body, it operates efficiently within a temperature range of 0 to 40 °C, making it ideal for various indoor applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emergency Recessed Luminaire, Emergency Downlight, Emergency Exit Light, Emergency LED Light
Technical Specifications
- IP Rating: IP44 front face only
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Frequency: 50 Hz
- Maximum Wattage: 1.6 W
- Standby Power: 0.45 W
- Driver Type: Fixed output, included
- Wiring Type: Re-wireable flex & plug (2 pin), 1200 mm lead
- Emergency Mode: Non-maintained
- Emergency Classification: C0:D50, C90:D50
- Emergency Output Power: 1500 mW
- Emergency Duration: 90 minutes
- Emergency Lumen Output: 250 lm
- Body Material: Polycarbonate
- Working Temperature Range: 0 to 40 °C
- Product Design Life: 6 years
- Dimensions (H x L x W): 50mm x 150mm x 150mm
- Weight: 0.5 kg
Key Features
- IP44 rated front face for moisture resistance
- Non-maintained emergency mode with 90 minutes duration
- Fixed output driver included
- Re-wireable flex & plug with 1200 mm lead
- Emergency lumen output of 250 lm
- Polycarbonate body material for durability
- Operating temperature range from 0 to 40 °C
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with safety standards and proper emergency lighting functionality.
Applications
- Emergency lighting in commercial buildings
- Safety lighting in public and residential spaces
- Recessed emergency luminaire for indoor use
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for Emergency Lighting
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance
- AS/NZS 2293.3 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Low power consumption with 1.6 W maximum wattage
- Long product design life of 6 years reduces waste
- Energy-efficient LED technology
Warranty Information
5 years return to base (RTB) warranty for commercial use.
Available Now
The Ledfire Core Emergency Luminaire Black - D50 by Ektor is available now for immediate purchase. Ideal for commercial and public building emergency lighting applications.
