Ledfire Pro Emergency Luminaire Black | IP44 Rated | Non-Maintained Mode | 90 Min Emergency Duration | by Ektor
Ledfire Pro Emergency Luminaire Black is designed for reliable emergency lighting in commercial and public buildings. With an IP44 rating for moisture resistance and a non-maintained mode providing 90 minutes of emergency illumination, this recessed light ensures safety compliance. Built with a durable polycarbonate body, it features a maximum wattage of 2.5 W and an emergency lumen output of up to 380 lm, making it an ideal choice for emergency exit routes and safety lighting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emergency LED Luminaire, Emergency Exit Light, Recessed Emergency Light, Wireless Emergency Luminaire
Technical Specifications
- IP Rating: IP44 front face only
- Body Material: Polycarbonate
- Installation Type: Recessed
- Working Temperature Range: 0 to 40 °C
- Input Frequency: 50 Hz
- Input Voltage: 230Vac (-6%/+10%)
- Maximum Wattage: 2.5 W
- LED Wattage: 4.3 W
- Standby Power: 0.25 W
- Emergency Mode: Non-Maintained
- Emergency Duration: 90 minutes
- Emergency Output Power: 2900 mW
- Emergency Lumen Output: 320 lm to 380 lm depending on model
- Driver Type: Wireless IEC62386-104 with DALI DT1
- Dimmable: No
- Flex & Plug Length: 1200 mm typical
- Emergency Control: DALI Monitored and Wireless IEC62386-104
- Dimensions (H x L x W): 100mm x 150mm x 150mm
- Weight: 1.2 kg
Key Features
- IP44 rated front face for moisture resistance
- Non-maintained emergency mode with 90 minutes duration
- Wireless IEC62386-104 DALI DT1 emergency control and monitoring
- Polycarbonate body for durability
- Recessed installation type
- Maximum wattage 2.5 W with LED wattage 4.3 W
- Standby power consumption 0.25 W
- Emergency lumen output up to 380 lm
- Supports emergency test and monitoring over DALI and wireless protocols
- Product design life of 12 years
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure compliance with safety and emergency lighting standards.
Applications
- Commercial and public buildings requiring emergency lighting
- Recessed installation in ceilings for emergency illumination
- Emergency exit routes and safety lighting compliance
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for Emergency Lighting Control Gear
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics
- AS/NZS 2293.3 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Low standby power consumption reduces energy waste
- Long product design life minimizes replacement frequency and waste
- Energy-efficient LED technology reduces overall power usage
Warranty Information
8 years return to base (RTB) warranty for commercial use.
Available Now
The Ektor Ledfire Pro Emergency Luminaire Black - D80 is available for immediate purchase, ideal for commercial and public building emergency lighting applications.
