Legrand 22 Way IP2X Terminal Block | Blue Removable Cover | 100A Max | by Legrand
The Legrand 22 Way IP2X Terminal Block is designed for reliable electrical distribution, featuring a durable brass and zinc-plated construction with a blue removable cover for easy identification. Rated for up to 100A at 400V, it's perfect for residential, commercial, and industrial applications, ensuring safe and efficient connections in electrical panels.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Brass and zinc-plated bichromated steel
- Voltage Rating: 400 V~
- Current Rating: 100 A max with 25 mm² input, 80 A max with 16 mm² input
- IP Rating: IP2X
- Number of Connections: 1 x 6 to 25 mm² + 21 x 1.5 to 16 mm²
- Mounting: Symmetrical or asymmetrical rail with universal support or 12 x 2 flat rail
- Cover: Blue, removable
- Dimensions (H x L x W): 30mm x 88mm x 176mm
- Weight: 0.15 kg
Key Features
- Constructed with brass and zinc-plated bichromated steel for durability
- Blue removable cover for easy identification of neutral or phase
- IP2X rated for safety
- Supports up to 100 A max at 400 V~ with 25 mm² input
- Supports up to 80 A max at 400 V~ with 16 mm² input
- Mountable on symmetrical or asymmetrical rail with universal support or on 12 x 2 flat rail
- Number of connections: 1 x 6 to 25 mm² + 21 x 1.5 to 16 mm²
- Supplied ready for use with screws not tightened
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper mounting.
Applications
- Electrical distribution and connection in residential, commercial, and industrial electrical panels
- Use with Plexo³ range, HL, and XL³ 125 enclosures
- Suitable for mounting on symmetrical or asymmetrical rails in electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste
- Supports efficient electrical distribution, contributing to energy management
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Legrand 22 Way IP2X Terminal Block with Blue Cover is available for immediate purchase, ideal for electrical distribution applications in residential, commercial, and industrial settings.
