LiDAR Sensor AOS101 | 270° Aperture Angle | 18m Range | IP65/IP67 Rated | by SICK
The AOS101 LiDAR Sensor is designed for precise object detection in industrial automation, featuring a 270° aperture angle and a maximum range of 18 meters. With an IP65/IP67 rated enclosure, it ensures robust protection against environmental factors, making it ideal for various applications including intrusion detection and environmental monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor model: LMS111-10100S01
- Number of sensors: 1
- Aperture angle: 270°
- Max range with 10% reflectivity: 18 m
- Supply voltage: 24 V DC
- Power consumption: 8 W per LMS111 (+ heating 35 W per LMS)
- Enclosure rating: IP65/IP67 (sensor), IP20 (control)
- Response time: 240 ms
- Number of safety inputs: 8
- Number of safe outputs: 4
- Configuration interface: Ethernet (sensor), USB (control)
- Operating temperature: -30°C to +50°C (sensor), -25°C to +55°C (control)
- Storage temperature: -30°C to +70°C (sensor), -25°C to +70°C (control)
- Ambient light immunity: 40,000 lx
- Vibration resistance: IEC 60068-2-6:2007-12
- Shock resistance: IEC 60068-2-27:2008-03
- Dimensions (H x L x W): 162mm x 102mm x 105mm
- Weight: 1.1 kg
Key Features
- Single LMS111-10100S01 sensor with 270° aperture angle
- Maximum range of 18 m with 10% reflectivity
- IP65/IP67 rated sensor enclosure for robust environmental protection
- Ethernet and USB configuration interfaces
- 8 safety inputs and 4 safe outputs for system integration
- Response time of 240 ms
- Operating temperature range from -30°C to +50°C (sensor) and -25°C to +55°C (control)
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with electrical standards.
Applications
- Object detection in industrial automation
- Non-safety LiDAR scanning for environment monitoring
- Intrusion detection and warning systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
- AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient monitoring and automation reducing energy waste
- Durable IP65/IP67 housing extends product life reducing replacement waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK AOS101 LiDAR Object Detection System is available for immediate purchase, ideal for industrial automation and object detection applications.
