Limit Switch NEMA Type 4/13 | Oil-Tight Construction | Plug-in Lever Type | 2-Circuit Operation | by Allen-Bradley
The Allen-Bradley 802TA5P Limit Switch features NEMA Type 4/13 oil-tight construction and a plug-in lever type design, making it ideal for industrial automation control systems. With a maximum voltage of 600 VAC and a current rating of 10 AMP, this switch ensures reliable operation in machinery safety and position detection applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- NEMA Type 4/13 oil-tight construction
- Plug-in lever type with spring return
- Standard operating torque
- 2-circuit configuration
- Clockwise and counterclockwise operation only
- Maximum voltage: 600 VAC
- Maximum current: 10 AMP
- Dimensions (H x L x W): 80mm x 40mm x 60mm
- Weight: 0.5 kg
Key Features
- NEMA Type 4/13 rated for oil-tight construction
- Plug-in design for easy installation and maintenance
- Lever type actuator with spring return
- Standard operating torque
- 2-circuit operation
- Supports clockwise and counterclockwise operation
- Maximum voltage rating of 600 VAC
- Maximum current rating of 10 AMP
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Industrial automation control systems
- Machinery safety and position detection
- Manufacturing process control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable oil-tight construction reduces environmental contamination risk
- Long service life reduces waste and replacement frequency
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 802TA5P Limit Switch is available for immediate purchase, ideal for industrial automation and machinery safety applications.
