Linear Changeover Switch 1 NO + 1 NC | 20A 250V AC | 2 Positions by Clipsal
Linear changeover switch with 1 NO + 1 NC configuration and 20A, 250V AC rating—ideal for residential and small commercial spaces. Built for easy installation with DIN rail mounting and toggle control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, Linear switch, 1 NO + 1 NC, 20A, 250 V AC, 2 positions
Brand: Clipsal
SKU: A9E18072
Alternatively Known As: Acti9 Switch, Changeover Switch, Linear Switch
Technical Specifications
- Rated operational voltage: 250V AC 50/60Hz
- Electrical durability: AC-22: 30000 cycles
- IP Rating: IP20
- Relative humidity: 95% at 55°C
- Ambient air temperature for operation: -20...50°C
- Ambient air temperature for storage: -40...70°C
- Tropicalisation: 2
- Pollution degree: 3
- Dimensions (H x L x W): 82mm x 75mm x 18mm
- Weight: 0.045 kg
Key Features
- Changeover switch with 1 NO + 1 NC configuration.
- Rated operational current of 20A and voltage of 250V AC.
- Toggle control type with 2 positions.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments
- Commercial: Small commercial spaces
Standards & Compliance
- Complies with IEC 60669-1 and IEC 60947-5-1.
Environmental Benefits
- Complies with IEC standards for safety and performance.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Linear Switch 1 NO + 1 NC 20A 250V AC is available now for immediate purchase. Ideal for residential and small commercial electrical circuit control.
