LMC132-11101 VdS Infrared Security Sensor | IP67 Rated | 270° Horizontal Aperture | by SICK
The LMC132-11101 VdS Infrared Security Sensor is designed for robust security applications, featuring a wide horizontal aperture of 270° and an IP67 rated enclosure for dust and water protection. Ideal for both indoor and outdoor environments, this sensor ensures reliable object detection and perimeter protection, making it perfect for industrial safety monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: LMC132-11101 VdS Infrared Security Sensor | IP67 Rated | 270° Horizontal Aperture | by SICK
Brand: SICK
SKU: 1051488
Alternatively Known As: LMS13x VdS Sensor, SICK Infrared Security Sensor, Outdoor Security Laser Scanner
Technical Specifications
- Power supply voltage: 9 V DC to 30 V DC
- Typical power consumption: 8 W, up to 35 W with heating
- Response time: ≥ 20 ms
- Systematic error: ± 30 mm
- Statistical error: 12 mm
- Object remission range: 2% to over 1000% (reflectors)
- Electromagnetic compatibility: EN 61000-6-2:2005 / EN 61000-6-4 (2007-01)
- Vibration resistance: EN 60068-2-6 (1995-04)
- Shock resistance: EN 60068-2-27 (1993-03)
- Operating temperature range: -30 °C to +50 °C
- Storage temperature range: -30 °C to +70 °C
- Ambient light immunity: 40,000 lx
- Connection type: 1 x M12 round connector
- Enclosure rating: IP67
- Protection class: III (EN 50178)
- Dimensions (H x L x W): 152mm x 105mm x 102mm
- Weight: 1.1 kg
Key Features
- Infrared light source with 905 nm wavelength
- Laser class 1 compliant with IEC 60825-1:2014 standards
- Wide horizontal aperture angle of 270° with 0.25° angular resolution
- Scanning frequency of 50 Hz
- Working range from 0.5 m to 20 m, with scanning range up to 18 m at 10% remission factor
- IP67 rated enclosure for dust and water protection
- Robust housing in black (RAL 9005) color
- Multiple interfaces including Ethernet (TCP/IP), RS-232 serial, and CAN
- Digital inputs and outputs with relay and digital options
- Heating function for operation in cold environments
- High mean time between failures (MTBF) and MTTFD greater than 100 years
- Integrated field evaluation and security parameterization with up to 10 field sets
Professional Installation Requirements
- Installation by qualified professionals is recommended to ensure compliance with safety and operational standards.
Applications
- Security systems for outdoor and indoor environments
- Industrial safety monitoring
- Object detection and perimeter protection
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements
- Low power consumption with efficient heating system
- Long operational life reduces electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK LMC132-11101 VdS sensor is available for immediate purchase, ideal for security and safety applications in both outdoor and indoor environments.
