Lockable Door Coupling Handle | Emergency Stop Function | Red Color | PKZ0-XRH by Eaton
The PKZ0-XRH lockable door coupling handle features an emergency stop function and is designed for use with PKZ0 systems. Ideal for industrial applications, it supports safety compliance and is fitted with an extension shaft for up to 3 padlocks, ensuring secure operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Lockable Door Coupling Handle | Emergency Stop Function | Red Color | PKZ0-XRH by Eaton
Brand: Eaton
SKU: Y7-106133
Alternatively Known As: PKZ0 Door Coupling Handle, Emergency Stop Handle, Lockable Door Handle for PKZ0
Technical Specifications
- Product Length/Depth: 235 mm
- Product Height: 66 mm
- Product Width: 64 mm
- Product Weight: 0.16 kg
- Color: Red
- Lockable with extension shaft for 3 padlocks (4 - 8 mm hasp thickness)
- Suitable as main switch with Emergency-Stop function to EN 60204
- Ambient operating temperature range: -25 °C to 55 °C
- Certifications: CSA Class No.: 3211-05, CSA-C22.2 No. 14, UL 508, UL CE, CSA IEC/EN 60947-4-1
- Meets product standard requirements for corrosion resistance, thermal stability, and insulation material resistance
- Dimensions (H x L x W): 66mm x 235mm x 64mm
- Weight: 0.16 kg
Key Features
- Lockable door coupling handle
- Fitted with extension shaft for 3 padlocks, 4 - 8 mm hasp thickness
- ON/OFF switch position and '+' (tripped) indication
- Suitable for emergency stop function
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with emergency stop systems and electrical safety standards.
Applications
- Suitable for use as a main switch with Emergency-Stop function to EN 60204
- Used with PKZ0-XRH for emergency stop applications
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Supports safety compliance reducing risk of accidents and associated environmental hazards
Warranty Information
Warranty details available upon request from Eaton; typically includes coverage against manufacturing defects.
Available Now
The Eaton Moeller PKZ0 Door Coupling Handle is available for immediate purchase, ideal for emergency stop applications in industrial and commercial electrical switchgear.
