LOCKWOOD 1801 Square End Plate with Cylinder Hole | Solid Brass | Satin Chrome Finish | by Lockwood
The LOCKWOOD 1801 Square End Plate with Cylinder Hole is crafted from high-quality solid brass, ensuring durability and corrosion resistance. Designed for both commercial and residential applications, this plate features a unique mechanism that adjusts to suit door thickness, making it ideal for various door hardware solutions. With a stylish satin chrome finish, it combines functionality with aesthetic appeal, perfect for institutional and industrial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: LOCKWOOD 1801 Square End Plate with Cylinder Hole | Solid Brass | Satin Chrome Finish | by Lockwood
Brand: Lockwood
SKU: 1801/70SC
Alternatively Known As: Lockwood Brass Door Plate, Lockwood 1801 End Plate, Lockwood Cylinder Hole Plate, Lockwood 70 Lever Plate
Technical Specifications
- Handing: Plates are not handed; symmetrical levers may be reversed by removing stop screw
- Fixing: Plates designed to fit back to back; concealed fixing on outside requires visible fixing on inside
- Door Thickness Compatibility: Suitable for doors 32 to 50mm thick
- Material: Solid brass
- Finish: Standard satin chrome brushed finish
- Durability: Tested to D8 rating (500,000 cycles) per AS4145.2: 2008
- Corrosion Resistance: Passes C10 neutral salt spray test for over 1000 hours
- Dimensions (H x L x W): 150mm x 20mm x 70mm
- Weight: 0.5 kg
Key Features
- Architecturally designed plates offering style and versatility
- Made from high quality solid brass for durability and corrosion resistance
- Unique mechanism adjusts tail bar length to suit door thickness
- Tested to exceed highest durability rating (D8, 500,000 cycles) under AS4145.2: 2008
- Corrosion resistant, suitable for coastal and high corrosion environments
- Manufactured in Australia at ISO 14001 accredited facility
Professional Installation Requirements
- Professional installation by a qualified locksmith or door hardware specialist is recommended to ensure proper fitting and function.
Applications
- Commercial: Institutional and industrial door furniture applications
- Residential: Suitable for use with Lockwood Selector & Synergy Series Mortice Latches
- Architectural: Designed for aesthetic and functional door hardware solutions
Standards & Compliance
- Complies with AS4145.2: 2008 for door hardware durability and corrosion resistance
Environmental Benefits
- Brass is highly recyclable and has good cradle-to-grave characteristics
- Manufactured locally in Australia reducing shipping energy and emissions
- High durability reduces need for replacement and waste
Warranty Information
Warranty details available upon request from Lockwood; typically includes coverage against manufacturing defects.
Available Now
The LOCKWOOD 1801 Square End Plate with Cylinder Hole & 70 Lever is available for immediate purchase, ideal for commercial, institutional, and residential door hardware applications.
