Long Range Barcode Scanner | IO-Link & USB Interfaces | IP65 Rated | by SICK
The Long Range Barcode Scanner CLV615-I2150 is designed for industrial automation, featuring IO-Link and USB interfaces for seamless integration. With a robust aluminum housing and an IP65 rating, it operates efficiently in various environments, making it ideal for logistics, warehousing, and manufacturing applications. Experience high scanning frequencies and compatibility with all current 1D barcode types for enhanced productivity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type: IO-Link and POWER 5-pin M12 male connector, Sensor 1 5-pin M12 female connector, Micro USB type B
- Supply voltage: 18 V DC to 30 V DC
- Power consumption: 3.2 W
- Housing material: Aluminum die cast
- Window material: Glass
- Enclosure rating: IP65
- Protection class: III (EN 60950-1/EN 62368-1)
- Reading distance: 25 mm to 330 mm
- Scanning frequency: 400 Hz to 1000 Hz
- Code resolution: 0.35 mm to 0.5 mm
- Readable code structures: 1D codes including Code 39, Code 128, Code 93, Codabar, UPC/GTIN/EAN, Interleaved 2 of 5
- Number of codes per scan: 1
- Number of characters per reading interval: 31
- EMC: EN 61000-6-4:2019 / EN 61000-6-2:2019
- Vibration resistance: EN 60068-2-6
- Shock resistance: EN 60068-2-27
- Operating temperature: 0°C to +40°C
- Storage temperature: -20°C to +70°C
- Relative humidity: 90%, non-condensing
- Ambient light immunity: 2000 lx on barcode
- Bar code print contrast (PCS): ≥ 60%
- Dimensions (H x L x W): 38mm x 80mm x 96mm
- Weight: 0.26 kg
Key Features
- Long range line scanner with fixed optical focus
- Side reading field of 105°
- Visible red laser light source at 655 nm
- Laser class 2 compliant with IEC 60825-1 standards
- High scanning frequency from 400 Hz to 1000 Hz
- Supports all current 1D barcode types including Code 39, Code 128, and UPC/EAN
- IO-Link V1.1 and USB interfaces for easy integration and configuration
- Robust aluminum die cast housing with IP65 rating
- Operating temperature range from 0°C to +40°C
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure proper integration and compliance with safety standards.
Applications
- Industrial automation for barcode reading
- Logistics and warehousing for package tracking
- Manufacturing for quality control and product identification
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient laser scanning reduces power consumption
- Durable housing extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK CLV615-I2150 Long Range IO-Link Line Scanner is available for immediate purchase, ideal for industrial automation and barcode reading applications.
