Low Profile Emergency Luminaire Slimfire D50 Black | IP44 Rated | Non-Maintained Emergency Mode | by Ektor
The Low Profile Emergency Luminaire Slimfire D50 in black is designed for recessed installation, featuring an IP44 rating for moisture protection and an IC-4 rating for safe insulation coverage. Ideal for both commercial and residential applications, this luminaire provides 90 minutes of emergency lighting with an output of 264 lumens, ensuring safety in emergency escape routes and exit pathways.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Low profile emergency light, recessed emergency luminaire, Slimfire emergency light, D50 emergency luminaire
Technical Specifications
- IP Rating: IP44 front face only
- IC Rating: IC-4 at maximum working temperature
- Body Material: Polycarbonate
- Installation Type: Recessed
- Working Temperature Range: 0 to 40 °C
- Input Frequency: 50 Hz
- Input Voltage: 230Vac (-6%/+10%)
- Maximum Wattage: 1 W
- Standby Power: 0.5 W
- Driver Type: Fixed output, integrated
- Dimmable: No
- Flex & Plug Length: 1200 mm
- Wiring Type: Non-rewireable flex & plug
- Emergency Mode: Non-maintained
- Emergency Classification: C0:D50, C90:D50
- Emergency Output Power: 2250 mW
- Emergency Duration: 90 minutes
- Emergency Lumen Output: 264 lm
- Product Design Life: 6 years
- Dimensions (H x L x W): 50mm x 150mm x 150mm
- Weight: 0.5 kg
Key Features
- Low profile recessed design
- IP44 rated front face for moisture protection
- IC-4 rated for safe insulation coverage
- Non-maintained emergency mode with 90 minutes duration
- Integrated fixed output driver included
- Non-dimmable
- Emergency lumen output of 264 lm
- Replacement battery code 01308
- 1200 mm non-rewireable flex and plug
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with Australian electrical and safety standards.
Applications
- Commercial and residential recessed emergency lighting
- Emergency escape routes and exit pathways
- Indoor environments requiring low profile emergency luminaires
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting Luminaires
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics of Electrical Lighting and Similar Equipment
Environmental Benefits
- Low power consumption with 1W maximum wattage
- Long product design life of 6 years reduces waste
- Energy efficient LED technology
Warranty Information
5 years return to base (RTB) commercial use warranty.
Available Now
The Ektor Slimfire Low Profile Emergency Luminaire D50 Black is available for immediate purchase, ideal for commercial and residential emergency lighting applications.
