Low Voltage Flat TPS Cable | 3 x 2.5mm² Copper | PVC Insulation | Blue Sheath | by Electra Cables
Low Voltage Flat TPS Cable with 3 x 2.5mm² copper conductors and PVC insulation is perfect for air conditioning installations. Designed for fixed wiring in dry locations, this cable ensures reliable power distribution and complies with Australian standards for electrical safety. The blue sheath provides easy identification, making it an ideal choice for both residential and commercial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Low Voltage Flat TPS Cable | 3 x 2.5mm² Copper | PVC Insulation | Blue Sheath | by Electra Cables
Brand: Electra Cables
SKU: AC76704-100BLU
Alternatively Known As: TPS cable, flat TPS cable, 3 core and earth cable, 2.5mm TPS, air conditioning cable, blue sheath TPS, low voltage flat cable
Technical Specifications
- Conductor: 3 x 2.5mm² copper + earth
- Insulation: PVC (Polyvinyl Chloride)
- Sheath: Blue PVC
- Voltage Rating: 450/750V
- Operating Temperature: -15°C to +90°C
- Standard Length: 100m roll
- Application: Fixed wiring in dry locations
- Dimensions (H x L x W): 5mm x 100000mm x 12mm
- Weight: 7.5 kg
Key Features
- 3 x 2.5mm² copper conductors plus earth for reliable power distribution
- Flat TPS (Thermoplastic Sheathed) design for easy installation
- PVC insulation and blue sheath for added protection and identification
- Low voltage cable suitable for 450/750V applications
- Complies with Australian standards for electrical safety
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Ideal for air conditioning installations in residential and commercial buildings
- Suitable for fixed wiring in dry locations
- Commonly used for lighting and power circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 5000.2 – Electric cables – Polymeric insulated – For working voltages up to and including 450/750V
Environmental Benefits
- PVC insulation is lead-free and compliant with RoHS standards
- Durable design reduces need for frequent replacement, minimizing waste
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
Available for immediate purchase. Ideal for air conditioning installations and general fixed wiring in residential and commercial environments.
