LV Switchgear Partition | Aluminum Construction | 12.5 mm Modular Spacing | Stainless Steel Finish by Eaton
This LV switchgear partition features a durable aluminum construction with a stainless steel finish and 12.5 mm modular spacing—ideal for low voltage switchgear assemblies. Built for industrial and commercial electrical installations, it ensures compliance with safety standards and provides effective internal separation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: LV Switchgear Partition | Aluminum Construction | 12.5 mm Modular Spacing | Stainless Steel Finish by Eaton
Brand: Eaton
SKU: Y7-166741
Alternatively Known As: LV Switchgear Partition, xEnergy LV Switchgear Separator, Eaton LV Switchgear Panel Partition
Technical Specifications
- Material: Aluminum
- Surface finishing: Stainless steel
- Modular spacing: 12.5 mm
- Suitable for enclosure building width: 1000 mm
- Suitable for enclosure building depth: 800 mm
- Weight: 2.5 kg
- Product dimensions (WxHxD): 902 mm x 744.47 mm x 40 mm
- Suitable for internal separation forms: 2a, 2b, 3a, 3b, 4a, 4b
- Construction type: Individual part
- RoHS compliant
- Dimensions (H x L x W): 744mm x 40mm x 902mm
- Weight: 2.5 kg
Key Features
- Partition for LV switchgear with modular spacing of 12.5 mm
- Constructed from aluminum with stainless steel surface finishing
- Suitable for internal separation forms 2a, 2b, 3a, 3b, 4a, and 4b
- Designed for enclosure building width of 1000 mm and depth of 800 mm
Professional Installation Requirements
- Installation should be performed by a qualified electrical professional to ensure compliance with safety standards and proper integration into LV switchgear systems.
Applications
- Electrical distribution systems requiring internal separation
- Low voltage switchgear assemblies
- Industrial and commercial electrical installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- Durable aluminum construction promotes long product life and recyclability
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton xEnergy Main LV switchgear partition XPPBMV10 is available for immediate purchase, ideal for use in industrial and commercial low voltage switchgear assemblies.
