LV Switchgear Partition | Galvanized Steel | Modular Spacing 12.5mm | Internal Separation Forms by Eaton
This LV switchgear partition features galvanized steel construction and a modular spacing of 12.5mm, making it ideal for internal separation in electrical distribution boards. Built for industrial and commercial applications, it ensures durability and compliance with AS/NZS 3000 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: LV Switchgear Partition | Galvanized Steel | Modular Spacing 12.5mm | Internal Separation Forms by Eaton
Brand: Eaton
SKU: Y7-284132
Alternatively Known As: LV switchgear partition, internal separation panel, electrical switchboard partition
Technical Specifications
- Material: Steel
- Surface finishing: Galvanized
- Color: Stainless steel
- Modular spacing: 12.5 mm
- Suitable for enclosure building depth: 600 mm
- Suitable for enclosure building width: 950 mm
- Suitable for internal separation forms: 2a, 2b, 3a, 3b, 4a, 4b
- Construction type: Assembly kit
- Dimensions (H x L x W): 50mm x 980mm x 340mm
- Weight: 5.4 kg
Key Features
- Galvanized steel construction for durability
- Modular spacing of 12.5 mm for flexible assembly
- Suitable for various internal separation forms (2a, 2b, 3a, 3b, 4a, 4b)
- Assembly kit type construction
Professional Installation Requirements
- Professional installation by a qualified electrician or electrical technician is recommended to ensure compliance with safety standards and proper assembly.
Applications
- Internal separation in LV switchgear assemblies
- Electrical distribution boards requiring internal partitions
- Industrial and commercial electrical panel construction
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Galvanized steel construction enhances product longevity reducing waste
- RoHS compliant materials minimize hazardous substances
Warranty Information
Warranty information available upon request from manufacturer.
Available Now
The Eaton xEnergy Main LV switchgear partition XPFCD2006 is available for immediate purchase, ideal for use in electrical switchgear and distribution board assemblies.
