LV Switchgear Partition | Modular Spacing 12.5mm | Durable Plastic | Gray by Eaton
This LV switchgear partition features a modular spacing of 12.5mm and is constructed from durable plastic, making it ideal for internal separation in electrical distribution assemblies. Designed for enclosures with a width of 1000mm and depth of 800mm, it ensures compliance with AS/NZS 3000 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: LV Switchgear Partition | Modular Spacing 12.5mm | Durable Plastic | Gray by Eaton
Brand: Eaton
SKU: Y7-166744
Alternatively Known As: LV Switchgear Partition, xEnergy LV Switchgear Separator, Eaton LV Panel Partition
Technical Specifications
- Material: Plastic
- Color: Gray (RAL 7035)
- Modular spacing: 12.5 mm
- Suitable for enclosure building width: 1000 mm
- Suitable for enclosure building depth: 800 mm
- Suitable for internal separation forms: 2a, 2b, 3a, 3b, 4a, 4b
- Construction type: Individual part
- Surface finishing: Other
- Dimensions (H x L x W): 798mm x 438mm x 923mm
- Weight: 1 kg
Key Features
- Partition for LV switchgear with modular spacing of 12.5 mm
- Constructed from durable plastic material
- Color: Gray (RAL 7035)
- Designed for internal separation forms 2a, 2b, 3a, 3b, 4a, and 4b
Professional Installation Requirements
- Installation should be performed by a qualified electrician familiar with LV switchgear assembly and compliance with AS/NZS 3000 standards.
Applications
- Internal separation in LV switchgear assemblies
- Suitable for enclosure building width 1000 mm and depth 800 mm
- Used in electrical distribution and control panels
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, ensuring reduced hazardous substances in manufacturing
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton xEnergy Main LV Switchgear Partition XPIX40BCB-E-10 is available for immediate purchase, ideal for use in electrical distribution and control panel assemblies.
