Lynk Duo Advanced Emergency Weatherproof Luminaire | IP65 & IK10 Rated | Wireless Control | Black | by Ektor
The Lynk Duo Advanced Emergency Weatherproof Luminaire is designed for reliable emergency lighting in commercial and industrial settings. With an IP65 weatherproof rating and IK10 impact resistance, this luminaire ensures durability and safety. Featuring wireless control options and a non-maintained emergency mode with a 90-minute duration, it’s perfect for both indoor and outdoor surface mount installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emergency Weatherproof Luminaire, Wireless Emergency Light, DALI Emergency Luminaire, Surface Mount Emergency Light
Technical Specifications
- IP Rating: IP65
- IK Rating: IK10
- Maximum Wattage: 2.5 W
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Frequency: 50 Hz
- Standby Power: 1 W
- Emergency Output Power: 2500 mW
- Emergency Duration: 90 minutes
- Emergency Lumen Output: 350 lm
- Operating Temperature Range: 0 to 40 °C
- Body and Diffuser Material: Polycarbonate
- Installation Type: Surface mount
- Driver Types: DALI DT1 Emergency, Wireless IEC62386-104 with DT1
- Wiring Type: Re-wireable terminal block (2 or 4 pin depending on model)
- Dimensions (H x L x W): 150mm x 100mm x 250mm
- Weight: 1.2 kg
Key Features
- IP65 weatherproof and IK10 impact resistant rating
- Adjustable fitting for directional lighting
- Non-maintained emergency mode with 90 minutes duration
- DALI DT1 and Wireless IEC62386-104 emergency control options
- Polycarbonate body and diffuser for durability
- Low standby power consumption of 1W
- Supports emergency test and monitoring over DALI and wireless protocols
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical and safety standards.
Applications
- Commercial and industrial emergency lighting
- Outdoor and indoor surface mount installations
- Emergency exit and safety lighting in public buildings
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for Emergency Lighting Control Gear
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics
- AS/NZS 2293.3 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Energy-efficient LED technology reduces power consumption during emergency operation
- Long product design life of 8 years minimizes waste and replacement frequency
Warranty Information
6 years return to base (RTB) commercial use warranty.
Available Now
The Lynk Duo Advanced Emergency Weatherproof Luminaire with Wireless by Ektor is available for immediate purchase, ideal for commercial and industrial emergency lighting applications.
