M10 Dome Head Rivet Nut | Zinc Plated Steel | Knurled Shaft | Chrome (VI)-Free | by Wurth
The M10 Dome Head Rivet Nut is crafted from zinc-plated steel, featuring a knurled shaft for enhanced tightening torque and secure fastening. Ideal for applications in construction, automotive, and manufacturing, this rivet nut is suitable for various materials including aluminium, plastic, and fibreglass, ensuring a strong screw connection in thin-walled structural elements.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M10 Dome Head Rivet Nut | Zinc Plated Steel | Knurled Shaft | Chrome (VI)-Free | by Wurth
Brand: Wurth
SKU: 94822010
Alternatively Known As: Rivet Nut, Blind Rivet Nut, Threaded Insert, Knurled Shaft Rivet Nut
Technical Specifications
- Material: Steel
- Surface: Zinc plated, blue passivated
- Thread type x nominal diameter (D): M10
- Length (l1): 24 mm
- Head diameter (d1): 16.0 mm
- Outer diameter (d2): 11.9 mm
- Head height (k1): 2.1 mm
- Min./max. grip range (s1): 3.0-6.0 mm
- Tensile fracture load: 29400 N
- Shear-fracture load: 4900 N
- Max. tightening torque: 32 Nm
- Drill hole diameter: 12.1 mm
- Shank detail: With knurled shank
- Head type: Dome head
- RoHS-compliant: Yes
- Dimensions (H x L x W): 24mm x 24mm x 16mm
- Weight: 0.1 kg
Key Features
- Chrome (VI)-free, compliant with EU End of Life Vehicles Directive
- Combines blind rivet and screw connection for secure fastening
- Knurled shaft increases tightening torque and resistance to turning
- Suitable for fastening various materials including aluminium, plastic, and fibreglass
Professional Installation Requirements
- Installation requires appropriate tools for rivet nut setting and should be performed by trained personnel to ensure proper fastening and safety.
Applications
- Fastening in thin-walled structural elements
- Suitable for aluminium, plastic, and fibreglass materials
- General fastening applications requiring strong screw connections
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Chrome (VI)-free surface treatment reduces environmental and health hazards
- RoHS-compliant material ensures reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth's warranty policy for details.
Available Now
Wurth Zinc-Plated Steel Rivet Nut M10 Dome Head is available for immediate purchase, ideal for fastening applications in construction, automotive, and manufacturing industries.
