M10 Metric Stud Bolt | 25mm Length | Steel Construction | DIN 939 Compliant | by Wurth
The M10 Metric Stud Bolt is designed for secure fastening in mechanical assemblies, automotive repairs, and construction applications. With a 25mm length and made from durable steel with a property class of 5.8, this bolt ensures strength and reliability. Its plain surface finish and RoHS compliance make it an environmentally safe choice for various industrial uses.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M10 Metric Stud Bolt | 25mm Length | Steel Construction | DIN 939 Compliant | by Wurth
Brand: Wurth
SKU: 2501025
Alternatively Known As: Metric Stud Bolt M10, M10 Threaded Stud, Steel Stud Bolt M10x25
Technical Specifications
- Thread type x nominal diameter (d1): M10
- Length (l1): 25 mm
- Thread length (metric thread) (l2): 18 mm
- Thread length 2 (metric thread) (l3): 12 mm
- Standards: DIN 939
- Material: Steel
- Property class: 5.8
- Surface: Plain
- RoHS-compliant: Yes
- Head type: Without head
- Drive type: Without drive
- Thread type: Metric thread
- Pitch: 1.5 mm
- Thread form: Standard metric thread
- Shank diameter: 10 mm
- Product class: A
- Dimensions (H x L x W): 25mm x 25mm x 10mm
- Weight: 0.1 kg
Key Features
- M10 nominal diameter with 25 mm length
- Metric thread with 1.5 mm pitch
- Made from steel with property class 5.8 for strength
- Plain surface finish
- Complies with DIN 939 standard
- RoHS-compliant ensuring environmental safety
Professional Installation Requirements
- Installation by a qualified technician or tradesperson is recommended to ensure proper fastening and safety.
Applications
- Mechanical assemblies requiring secure fastening
- Automotive repairs and manufacturing
- Industrial machinery and equipment
- Construction and structural applications
Standards & Compliance
- AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable steel construction promotes long product life and reduces waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Wurth M10 x 25mm Metric Threaded Stud Bolt is available for immediate purchase, ideal for mechanical, automotive, and construction fastening applications.
