M12 4-Pin Cable Assembly | IP67 Rated | 0.3m PUR Cable | Durable TPU Housing | by SICK
The M12 4-Pin Cable Assembly DSL-1204-T0M3 is designed for robust industrial automation and sensor connectivity. Featuring male and female M12 connectors, this 0.3m PUR cable ensures reliable performance in harsh environments with an IP67 rating. Built with durable TPU housing, it withstands operating temperatures from -25 °C to +80 °C, making it ideal for manufacturing applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, M12, 4-pin, A-coded
- Connection type head B: Female connector, M12, 4-pin, A-coded
- Connection type head C: Male connector, M12, 4-pin, A-coded
- Connecting cable length: 0.3 m
- Cable material: PUR
- Conductor cross section: 0.34 mm²
- Housing material: TPU
- Connector material head A and C: TPU
- Housing color: Orange
- Locking nut material: Zinc die-cast, nickel-plated
- Shielding: Unshielded
- Reference voltage: ≤ 60 V DC, ≤ 300 V DC
- Rated impulse voltage: 2 kV
- Current loading: 4 A
- Operating temperature: -25 °C to +80 °C
- Enclosure rating: IP67
- Dimensions (H x L x W): 12mm x 300mm x 12mm
- Weight: 0.1 kg
Key Features
- Male and female M12, 4-pin, A-coded connectors
- 0.3 m PUR cable with 0.34 mm² conductor cross section
- TPU housing and connector material for durability
- Zinc die-cast, nickel-plated locking nut
- Unshielded cable and connectors
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -25 °C to +80 °C
- Rated impulse voltage of 2 kV and current loading of 4 A
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation signal interrogation
- Sensor and actuator connectivity in manufacturing
- Robust connection in harsh environments requiring IP67 protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK DSL-1204-T0M3 M12 4-pin cable assembly is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
