M12 5-Pin Connector Cable | Female & Male Connectors | IP67 Rated | Durable TPU Housing | by SICK
The M12 5-Pin Connector Cable is designed for reliable industrial automation and sensor connectivity. Featuring female and male A-coded connectors, this durable cable with a TPU housing ensures secure connections in harsh environments. With an IP67 rating, it provides excellent dust and water protection, making it ideal for machine building and factory automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Female connector, M12, 5-pin, A-coded
- Connection type head B: Female connector, M12, 5-pin, A-coded
- Connection type head C: Male connector, M12, 5-pin, A-coded
- Housing material: TPU
- Locking nut material: Zinc die-cast, nickel-plated
- Shielding: Unshielded
- Current loading: ≤ 4 A
- Operating temperature: –30 °C to +90 °C
- Enclosure rating: IP67
- Dimensions (H x L x W): 10mm x 250mm x 10mm
- Weight: 0.1 kg
Key Features
- Female and male M12, 5-pin, A-coded connectors
- Durable TPU housing with black color
- Zinc die-cast, nickel-plated locking nut for secure connection
- Unshielded cable design
- Current loading up to 4 A
- Wide operating temperature range from -30°C to +90°C
- IP67 rated enclosure for dust and water protection
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation and sensor connectivity
- Machine building and factory automation
- Signal transmission in harsh environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- IP67 rating ensures long service life in harsh environments
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's warranty policy for details.
Available Now
The SICK DSC-1205T000025KM0 M12 Connector Cable is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
