M12 5-Pin Connector Cable | Male & Female A-Coded Connectors | IP67 Rated | by SICK
The M12 5-Pin Connector Cable is designed for robust industrial automation and sensor connectivity. Featuring male and female A-coded connectors, durable TPU housing, and an IP67 rating for dust and water protection, this cable is perfect for machine building and factory automation. With a wide operating temperature range from -25°C to +90°C, it ensures reliable performance in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, M12, 5-pin, A-coded
- Connection type head B: Female connector, M12, 5-pin, A-coded
- Connection type head C: Female connector, M12, 5-pin, A-coded
- Housing material: TPU
- Connector material head A and C: TPU
- Locking nut material: Nickel-plated brass
- Shielding: Unshielded
- Reference voltage: ≤ 36 V DC
- Current loading: 4 A
- Contamination rating: 3
- Special feature: Male insert rotated by 90°
- Operating temperature: –25 °C to +90 °C
- Enclosure rating: IP67
- Dimensions (H x L x W): 10mm x 150mm x 10mm
- Weight: 0.1 kg
Key Features
- Male and female M12, 5-pin, A-coded connectors
- TPU housing and connector material for durability
- Nickel-plated brass locking nut for secure connection
- Unshielded design
- Male insert rotated by 90° for flexible installation
- Operating temperature range from -25°C to +90°C
- IP67 rated enclosure for dust and water protection
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation and sensor connectivity
- Machine building and factory automation
- Signal transmission in harsh environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, reducing hazardous substances in electronics
- Durable TPU material extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK SBO-02D12-SFS01 M12 5-pin connector cable is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
