M12 8-Pin Connector Cable | Male & Female A-Coded | IP65/IP66K/IP67 Rated | by SICK
The M12 8-Pin Connector Cable is designed for reliable industrial sensor connectivity, featuring male and female A-coded connectors with a screw connection for secure attachment. With an IP65/IP66K/IP67 rating and a wide operating temperature range of -25°C to +85°C, this cable is perfect for harsh environments in industrial automation and machine building applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, M12, 8-pin, A-coded
- Connection type head B: Female connector, M12, 8-pin, A-coded
- Connection type head C: Female connector, M12, 8-pin, A-coded
- Locking plug connector: Screw connection
- Locking nut material: Zinc die-cast, nickel-plated
- Width across flats: 13 mm
- Tightening torque: 0.6 Nm
- Shielding: Unshielded
- Reference voltage: ≤ 60 V DC
- Rated impulse voltage: 0.8 kV
- Current loading: 2 A
- Insulation resistance: 100 MΩ
- Contamination rating: 3
- Overvoltage category: III
- Specific insulation resistance: 30 mΩ
- Enclosure rating: IP65 / IP66K / IP67
- Operating temperature: -25 °C to +85 °C
- UL File No.: E335179
- Dimensions (H x L x W): 13mm x 150mm x 13mm
- Weight: 0.1 kg
Key Features
- Male and female M12, 8-pin, A-coded connectors
- Screw connection locking plug for secure attachment
- Zinc die-cast, nickel-plated locking nut for durability
- Unshielded design suitable for standard industrial use
- High protection rating: IP65 / IP66K / IP67
- Wide operating temperature range from -25°C to +85°C
- Rated impulse voltage of 0.8 kV and current loading of 2 A
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation and sensor connectivity
- Machine building and factory automation
- Signal transmission in harsh environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- High ingress protection minimizes environmental damage risks
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK YM2A18-000S01FY2A8 M12 8-pin Connector Cable is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
