M12 8-Pin Connector Cable | Shielded | IP67 Rated | by SICK
The M12 8-pin connector cable is designed for industrial automation and sensor connectivity, featuring male and female A-coded connectors for secure connections. With a robust IP67 rating for dust and water resistance, this cable operates effectively in temperatures ranging from -25 °C to +85 °C, making it ideal for machine building and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, M12, 8-pin, A-coded
- Connection type head B: Female connector, M12, 8-pin, A-coded
- Connection type head C: Female connector, M12, 8-pin, A-coded
- Locking plug connector: Screw connection
- Locking nut material: Zinc die-cast, nickel-plated
- Width across flats: 13 mm
- Shielding: Shielded
- Rated impulse voltage: 0.8 kV
- Current loading: 2 A
- Insulation resistance: 100 MΩ
- Contamination rating: 3
- Overvoltage category: III
- Specific insulation resistance: 30 mΩ
- Enclosure rating: IP67
- Operating temperature: -25 °C to +85 °C
- UL File No.: E335179
- Dimensions (H x L x W): 10mm x 150mm x 13mm
- Weight: 0.1 kg
Key Features
- Male and female M12, 8-pin, A-coded connectors
- Shielded cable for interference protection
- Screw connection locking plug for secure attachment
- Zinc die-cast, nickel-plated locking nut for durability
- Rated impulse voltage of 0.8 kV and current loading of 2 A
- IP67 enclosure rating for dust and water resistance
- Operating temperature range from -25 °C to +85 °C
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation and sensor connectivity
- Machine building and factory automation
- Robotics and control systems requiring reliable M12 connections
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- Shielding minimizes electromagnetic interference, improving system efficiency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK YM2A28-000000FY2A8 M12 8-pin shielded connector cable is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
