M12 8-Pin Female Connector Cable | 10m Length | IP67 Rated | Shielded PVC | by SICK
The M12 8-Pin Female Connector Cable is designed for reliable sensor and actuator connections, featuring a 10m length and IP67 rating for dust and water protection. With a durable shielded PVC jacket and special color coding for easy identification, this cable is perfect for industrial applications in uncontaminated and chemical zones, ensuring optimal performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: M12 8-pin sensor cable, Female M12 connector cable, 10m sensor actuator cable, Shielded M12 cable
Technical Specifications
- Connection type head A: Female connector, M12, 8-pin, straight
- Connection type head B: Flying leads
- Connector material: PVC
- Locking nut material: Zinc die-cast, nickel-plated
- Cable length: 10 m
- Cable wires: 8-wire, PVC jacket
- Cable diameter: 6.1 mm
- Conductor cross section: 0.25 mm²
- Shielding: Shielded
- Bending radius: Flexible use > 10 x cable diameter
- Current loading: 2 A
- Signal type: Sensor/actuator cable
- Special feature: Special color code
- Enclosure rating: IP67
- Operating temperature: Flexible use +5 °C to +80 °C, Stationary position -40 °C to +80 °C, Head -25 °C to +90 °C
- Dimensions (H x L x W): 10mm x 10000mm x 10mm
- Weight: 0.2 kg
Key Features
- Female M12, 8-pin straight connector on head A
- Flying leads on head B
- Shielded 8-wire PVC cable with 10 m length
- IP67 rated enclosure for dust and water protection
- Special color code for easy identification
- Operating temperature range from -40°C to +90°C depending on position
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Sensor and actuator connections in uncontaminated zones
- Use in zones with chemical exposure
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable PVC jacket and shielding extend cable life reducing waste
- IP67 rating ensures protection against environmental ingress, reducing replacement frequency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's warranty policy for details.
Available Now
The SICK DOL-1208-G10MF M12 8-Pin Female Connector Cable 10m is available for immediate purchase, ideal for industrial sensor and actuator applications in uncontaminated and chemical zones.
