M12 Connector Cable Assembly | 5-Pin Male & 3-Pin Female | IP65/IP66K/IP67 Rated | by SICK
The M12 Connector Cable Assembly is designed for robust industrial automation and sensor connectivity. Featuring male and female M12 connectors with 5-pin and 3-pin A-coded configurations, this cable ensures secure connections with its screw locking mechanism. With an IP65/IP66K/IP67 enclosure rating, it provides excellent protection against dust and water, making it ideal for demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, M12, 5-pin, A-coded
- Connection type head B: Female connector, M12, 5-pin, A-coded
- Connection type head C: Female connector, M12, 3-pin, A-coded
- Locking plug connector: Screw connection
- Locking nut material: Zinc die-cast, nickel-plated
- Width across flats: 13 mm
- Tightening torque: 0.6 Nm
- Shielding: Unshielded
- Reference voltage: ≤ 60 V DC
- Rated impulse voltage: 1.5 kV
- Current loading: 4 A
- Insulation resistance: 100 MΩ
- Contamination rating: 3
- Overvoltage category: III
- Specific insulation resistance: 30 mΩ
- Enclosure rating: IP65 / IP66K / IP67
- Operating temperature: -25 °C to +85 °C
- UL File No.: E335179
- Dimensions (H x L x W): 20mm x 150mm x 13mm
- Weight: 0.1 kg
Key Features
- Male and female M12 connectors with 5-pin and 3-pin A-coded configurations
- Screw connection locking plug for secure attachment
- Zinc die-cast, nickel-plated locking nut for durability
- Unshielded design suitable for standard industrial environments
- High insulation resistance of 100 MΩ
- Contamination rating of 3 for reliable operation in industrial settings
- Overvoltage category III for enhanced electrical safety
- Enclosure rating IP65 / IP66K / IP67 for protection against dust and water
- Operating temperature range from -25 °C to +85 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation and control systems
- Sensor and actuator connectivity
- Factory and process automation
- Robotics and machinery wiring
Standards & Compliance
- AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Complies with China-RoHS for reduced hazardous substances
- Durable construction reduces replacement frequency and waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK YM2A15-000S01FY2A5 M12 Connector Cable Assembly is available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
